12V 4 Channel Relay Module: AE-04-012D-1-B-C (G2R)
The Technical Specifications of 12V 4 Channel Relay Module AE-04-012D-1-B-C (G2R):
- 12V 4 Channel OMRON G2R Relay Module
- 4 Channel Relay Board with LED Indication
- DIN Rail Mountable 4 Channel Relay with Freewheeling Diode
- Universal 4 Channel Relay Module for DIN Rail
- High Current 12V Relay Board with 4 SPDT Channels
- Rated Coil Current of 43.6mA
12V 4 Channel Relay Module AE-04-012D-1-B-C (G2R) Technical Specifications:
| Board Manufactures | Agility |
| Channels | 4 |
| Coil Voltage | 12VDC |
| Switching Current | 10A at 30VDC/250VAC |
| Contact Type 1C/O SPDT | 1C/O SPDT |
| Relay Make | OMRON G2R Series |
| Relay Actuation | LED Indication |
| Relay Coil Protection | Freewheeling Diode |
| Mounting | Universal DIN Rail |
| Dimension LxWxH (mm) | 66 x 90 x 68 |
| Power consumption | Approx. 530mW |
| Coil resistance (Ohms) | 275 |
| Rated coil current | 43.6mA |
| Must operate voltage | 80% max. of rated voltage |
| Must release voltage | 30% max. of rated voltage |
| Contact material | Ag-alloy (Cd free) |
| Maximum switching voltage | 380V AC, 125V DC |
| Contact resistance | 30mOhm max. |
| Operate time | 15 ms max |
| Release time | DC: 5 ms max. & AC: 10 ms max |
| Maximum voltage | 140% at 23°C |
| Ambient operating temperature | 0°C to 50°C |
| Housing material | PVC/V0 Grade, Phoenix Contact or equivalent |
| Housing color | Green |
| Conformal coating | Insulate, protect, and seal electronic parts, available on request |
| RoHS compliant | All the components used including PCBs are RoHS approved |
Are you looking for the 12V 4 Channel Relay Module AE-04-012D-1-B-C (G2R)? This module has four channels and uses a 12VDC coil voltage. It can switch currents up to 10A at 30VDC or 250VAC. Each channel is a 1C/O SPDT type, using the reliable OMRON G2R Series relays. It includes a freewheeling diode for coil protection and LED indication for relay actuation. The module is designed for universal DIN Rail mounting. For competitive prices on these relay modules, check out IndMALL Automation.
