BC15-LDT-C: Autonics 15mm Convergent Reflective Sensor
Technical Specifications of Autonics BC15-LDT-C:
Spec | Value |
---|---|
Sensing Type | Convergent reflective type |
Sensing Distance | 15mm |
Control Output | NPN open collector |
Connection Type | Connector type(M12) |
Autonics 15mm Convergent Reflective Sensor BC15-LDT-C Technical Specifications:
Specification | Value |
---|---|
Sensing type | Convergent reflective type |
Sensing distance | 15mm |
Sensing target | Color(opaque,translucent Material) |
Light source | Full Color LED(red, green,blue) |
Response time | 500㎲ |
Power supply | 12-24VDC ±10%(ripple P-P: max. 10%) |
Current consumption | Max. 30mA |
Sensitivity adjustment | 3-level |
Operation mode | color only,color + intensity |
Control output | NPN open collector |
Connection type | Connector type(M12) |
Environment_Ambient illumination | Incandescent lamp: Max. 3,000lx |
Environment_Ambient temperature | -10 to 55℃, storage: -25 to 75℃ |
Protection structure | IP67 |
Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
Material | Case: polycarbonate, Sensing part: acrylic, Bracket: stainless steel 304 , Bolt: carbon steel |
Weight | Approx. 80g(approx. 14g) |
