BTF30-DDTD: Autonics 30mm NPN Diffuse Sensor

Autonics BTF30-DDTD
Datasheet

Technical Specifications of Autonics BTF30-DDTD:

SpecValue
Sensing TypeDiffuse reflective type
Sensing Distance5 to 30mm
Control OutputNPN open collector
Connection TypeCable type(Ø2.5, 2m)

Autonics 30mm NPN Diffuse Sensor BTF30-DDTD Technical Specifications:

SpecificationValue
Sensing typeDiffuse reflective type
Sensing distance5 to 30mm
Sensing targetOpaque, Translucent material(min. sensing target: Ø0.2mm)
Light sourceRed LED(650nm)
Response timeMax. 1ms
Power supply12-24VDC ±10%(ripple P-P: max. 10%)
Current consumptionMax. 20mA
Sensitivity adjustment-
Operation modeDark ON
Control outputNPN open collector
Connection typeCable type(Ø2.5, 2m)
Environment_Ambient illuminationSunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination)
Environment_Ambient temperature-25 to 55℃, storage: -40 to 70℃
Protection structureIP67
Environment_Ambient humidity35 to 85% RH, storage: 35 to 85% RH
MaterialCase: polybutylene terephthalate, sensing part: polymethyl methacrylate,, bracket: SUS304(steel use stainless 304), bolt: carbon steel, sleeve: SUS304(steel use stainless 304
WeightApprox. 40g (approx. 25g)
Mail Us for your needs in Autonics 30mm NPN Diffuse Sensor BTF30-DDTD with budget-friendly prices. The Main Technical Parameters of BTF30-DDTD include Diffuse reflective type, 5 to 30mm Sensing Distance, Red LED(650nm) light source, 12-24VDC ±10%(ripple P-P: max. 10%) power supply, Max. 20mA current consumption, Dark ON, NPN open collector output, Cable type(Ø2.5, 2m), IP67 Protection structure. Customize Your Experience with a Quote for your requirement of Autonics 30mm NPN Diffuse Sensor. Experience the difference with our competitive pricing and superior support over other Suppliers.
