BUP-30S-P: Autonics Infrared Photo Sensor
Technical Specifications of Autonics BUP-30S-P:
Spec | Value |
---|---|
Sensing Type | Through-beam type |
Sensing Distance | 30mm |
Control Output | PNP open collector |
Connection Type | Cable type(Ø4, 2m) |
Autonics Infrared Photo Sensor BUP-30S-P Technical Specifications:
Specification | Value |
---|---|
Sensing type | Through-beam type |
Sensing distance | 30mm |
Sensing target | Opaquematerial of min. Ø1.5mm |
Light source | Infrared LED(940nm) |
Response time | Max. 1ms |
Power supply | 12-24VDC ±10%(ripple P-P: max. 10%) |
Current consumption | Max. 30mA |
Sensitivity adjustment | Sensitivity adjuster |
Operation mode | Light ON/Dark ON(set by control wire) |
Control output | PNP open collector |
Connection type | Cable type(Ø4, 2m) |
Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
Environment_Ambient temperature | -10 to 60℃, storage: -25 to 70℃ |
Protection structure | IP66 |
Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
Material | Case: Acrylonitrile butadiene styrene, Cap: Polycarbonate |
Weight | Approx. 85g |
Obtain a Quote for Autonics Infrared Photo Sensor BUP-30S-P at economical prices. Specifications Overview for BUP-30S-P reveals Through-beam type, 30mm Sensing Distance, Infrared LED(940nm) light source, 12-24VDC ±10%(ripple P-P: max. 10%) power supply, Max. 30mA current consumption, Light ON/Dark ON(set by control wire), PNP open collector output, Cable type(Ø4, 2m), IP66 Protection structure. Take the First Step with a Quote for your requirement of Autonics Infrared Photo Sensor. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
