BX5M-MFR: Autonics 5m Retroreflective Sensor
Technical Specifications of Autonics BX5M-MFR:
| Spec | Value |
|---|---|
| Sensing Type | Retroreflective type(standard type) |
| Sensing Distance | 5m(MS-2) |
| Control Output | Relay |
| Connection Type | Terminal block type |
Autonics 5m Retroreflective Sensor BX5M-MFR Technical Specifications:
| Specification | Value |
|---|---|
| Sensing type | Retroreflective type(standard type) |
| Sensing distance | 5m(MS-2) |
| Sensing target | Opaque material of min. Ø60mm |
| Light source | Infrared LED(850nm) |
| Response time | Max. 20ms |
| Power supply | 24-240VAC~ ±10% 50/60Hz, 24-240VDC ±10%(ripple P-P: max. 10%) |
| Current consumption | Max. 3VA |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by switch) |
| Control output | Relay |
| Connection type | Terminal block type |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -20 to 55℃, storage: -25 to 70℃ |
| Protection structure | IP66 |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | Case, Lens cover: Polycarbonate, Sensing part: Acrylic, Bracket: Steel plate cold commercial, Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum |
| Weight | Approx. 130g |
Talk to Our Engineer for Autonics 5m Retroreflective Sensor BX5M-MFR with exclusive offers. Core System Specifications of BX5M-MFR are Retroreflective type(standard type), 5m(MS-2) Sensing Distance, Infrared LED(850nm) light source, 24-240VAC~ ±10% 50/60Hz, 24-240VDC ±10%(ripple P-P: max. 10%) power supply, Max. 3VA current consumption, Light ON/Dark ON(set by switch), Relay output, Terminal block type, IP66 Protection structure. Don't Miss Out on a Quote for your requirement of Autonics 5m Retroreflective Sensor. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
