Autonics PRDCM08-4DN - Long-Distance Inductive Sensor
Technical Specifications of Autonics Long-Distance Inductive Sensor PRDCM08-4DN:
Spec | Value |
---|
Sensing distance | 4mm |
Control output | NPN Normally Open |
Wire type and power | DC 3-wire type 12-24VDC @(=) |
Protection structure | IP67(IEC standard) |
Autonics Long-Distance Inductive Sensor PRDCM08-4DN Technical Specifications
Specification | Value |
---|
Sensing side diameter | M8 |
Sensing distance | 4mm |
Hysteresis(distance) | Max. 15% of sensing distance |
Standard sensing target | 12×12×1mm(iron) |
Current specification | Current consumption: Max. 10mA |
Control output | NPN Normally Open |
Wire type and power | DC 3-wire type 12-24VDC @(=) |
Installation | Non-flush |
Cable Standard/material | Standard connector |
Body length | Standard type |
Affection by temperature | ≤ ± 10 % for sensing distance at ambient temperature 20 ℃(DIA. of sensing side Ø 8 mm: ≤ ± 15 %) |
Residual voltage | Max. 2V |
Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
Protection structure | IP67(IEC standard) |
Material | Case/Nut: Nikel plated Brass, (connector case of DIA. of sensing side Ø 8 mm: SUS303),washer: Nikel plated Iron, sensing side: polybutylene terephthalate,standard cable (black): polyvinyl chloride (PVC),oil resistant cable (gray): oil resistant polyvinyl chloride (PVC) |
Response frequency | 800Hz |
Weight | Approx. 12g(approx. 32g) |
