Applicable fluid | (Pneumatic type) Air, Non-corrosive gas |
Pressure type | Compound pressure |
Rated pressure range | -100.0 to 100.0kPa |
Protection structure | IP40 |
Pressure port | R1/8 |
Power supply | 12-24VDC @(=) ±10%(ripple P-P: max. 10%) |
Current consumption | Max. 50mA |
Pressure port direction | Rear fitting |
Connection type | Connector type(connector type cable: 2m) |
Display pressure unit | MPa, kPa, kgf/cm², bar, psi, mmHg, inHg, mmH₂O |
Control output_Hysteresis | Min. display interval |
Control output_Repeat error | ±0.2% F.S. ±Min. display interval |
Control output_Response time | Select one: 2.5ms, 5ms, 10ms, 25ms, 50ms, 100ms, 250ms, 500ms, 1,000ms, 5,000ms |
Control output | Select one at parameter settingNPN open collector outputPNP open collector output |
Environment_Ambient temperature | -10 to 50℃, storage: -20 to 60℃ |
Environment_Ambient humidity | 30 to 80% RH, storage: 30 to 80% RH |
Material | Front case: polycarbonate, Rear case: Polybutylene terephthalate + glass 15%, Pressure port: stainless steel 303 |
Weight | Approx. 165g(approx. 80g) |
