SR2-1415: Autonics 24V 2-phase Solid State Relay
Technical Specifications of Autonics 24V 2-phase Solid State Relay SR2-1415
| Spec | Value |
|---|---|
| Control phase | 2-Phase |
| Mounting type | Panel |
| Rated input voltage | 4-30VDC |
| Rated load current | 15A |
Autonics 24V 2-phase Solid State Relay SR2-1415 Technical Specifications:
| Specification | Value |
|---|---|
| Control phase | 2-Phase |
| Mounting type | Panel |
| Rated input voltage | 4-30VDC |
| Rated load voltage | 24-240VAC~ |
| Dielectric strength | 2,500VAC~ |
| Rated load current | 15A |
| Function | Zero cross turn-on |
| Environment_Ambient temperature | -30 to 80℃(in case of the rated input voltage 90-240VAC~: -30 to 70℃), Storage: -30 to 100℃( The rated load current capacity is different depending on ambient temperature. Refer to '▣ SSR Derating Curve'.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | approx. 365g(approx. 275g) |
Please speak to our Technical Engineer for Autonics 24V 2-phase Solid State Relay SR2-1415 at attractive prices. Technical Specs Summary of SR2-1415 includes 2-Phase, Panel mounting, 4-30VDC input voltage, 24-240VAC~ load voltage, 15A load current, Zero cross turn-on function. Match Your Needs with a Quote for your requirement of Autonics 24V 2-phase Solid State Relay. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
