SR2-4415: Autonics 15Amp 2-pole SSR Relay
Technical Specifications of Autonics 15Amp 2-pole SSR Relay SR2-4415
Spec | Value |
---|---|
Control phase | 2-Phase |
Mounting type | Panel |
Rated input voltage | 90-240VAC~ |
Rated load current | 15A |
Autonics 15Amp 2-pole SSR Relay SR2-4415 Technical Specifications:
Specification | Value |
---|---|
Control phase | 2-Phase |
Mounting type | Panel |
Rated input voltage | 90-240VAC~ |
Rated load voltage | 48-480VAC~ |
Dielectric strength | 2,500VAC~ |
Rated load current | 15A |
Function | Zero cross turn-on |
Environment_Ambient temperature | -30 to 80℃(in case of the rated input voltage 90-240VAC~: -30 to 70℃), Storage: -30 to 100℃( The rated load current capacity is different depending on ambient temperature. Refer to '▣ SSR Derating Curve'.) |
Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
Weight | approx. 365g(approx. 275g) |
Mail Us for Autonics 15Amp 2-pole SSR Relay SR2-4415 at the lowest pricing. Technical Specs Summary of SR2-4415 are 2-Phase, Panel mounting, 90-240VAC~ input voltage, 48-480VAC~ load voltage, 15A load current, Zero cross turn-on function. Take the First Step with a Quote for your requirement of Autonics 15Amp 2-pole SSR Relay. Choose us for unparalleled pricing and support over other Dealers & Distributors.
