SRC1-1420-N: Autonics 5V 20A Single-phase Relay
Technical Specifications of Autonics 5V 20A Single-phase Relay SRC1-1420-N
| Spec | Value |
|---|---|
| Control phase | Single-phase |
| Mounting type | Panel |
| Rated input voltage | 4-30VDC |
| Rated load current | 20A |
Autonics 5V 20A Single-phase Relay SRC1-1420-N Technical Specifications:
| Specification | Value |
|---|---|
| Control phase | Single-phase |
| Mounting type | Panel |
| Rated input voltage | 4-30VDC |
| Rated load voltage | 48-480VAC~ |
| Dielectric strength | 2500VAC~ 50/60Hz 1 min (Input-Output, Input/Output-Case) |
| Rated load current | 20A |
| Function | Zero cross turn-on |
| Environment_Ambient temperature | -30 to 80℃(in case of the rated input voltage 90-240VAC~: -20 to 70℃), storage: -30 to 100℃ (The rated load current capacity is diferent depending on ambient temperature. Refer to '▣ SSR Derating Curve'.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | Approx. 119g(approx. 85g) |
Ask for the Pricing of Autonics 5V 20A Single-phase Relay SRC1-1420-N at unbeatable prices. Detailed Specifications of SRC1-1420-N feature Single-phase, Panel mounting, 4-30VDC input voltage, 48-480VAC~ load voltage, 20A load current, Zero cross turn-on function. Now's the Time to Secure a Quote for your requirement of Autonics 5V 20A Single-phase Relay. We're committed to offering more favorable pricing and more responsive support than other Traders.
