SRH1-1430-N: Autonics 30 Amp Solid State Relay
Technical Specifications of Autonics 30 Amp Solid State Relay SRH1-1430-N
| Spec | Value |
|---|---|
| Control phase | Single-phase |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 4-30VDC |
| Rated load current | 30A |
Autonics 30 Amp Solid State Relay SRH1-1430-N Technical Specifications:
| Specification | Value |
|---|---|
| Control phase | Single-phase |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 4-30VDC |
| Rated load voltage | 48-480VAC~ |
| Dielectric strength | 2500VAC~ 50/60Hz 1 min (Input-Output, Input/Output-Case) |
| Rated load current | 30A |
| Function | Zero cross turn-on |
| Environment_Ambient temperature | -30 to 80℃, storage: -30 to 100℃(The rated load current capacity is different depending on ambient temperature. Refer to '▣ SSR Derating Curve'.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | Approx. 500g(approx. 410g) |
Reach Us by Email for Autonics 30 Amp Solid State Relay SRH1-1430-N: Autonics 30 Amp Solid State Relay at Discounted Rates. Key Technical Features of SRH1-1430-N are Single-phase, Panel, DIN rail mounting, 4-30VDC input voltage, 48-480VAC~ load voltage, 30A load current, Zero cross turn-on function. Navigate Your Needs with a Quote for your requirement of Autonics 30 Amp Solid State Relay. Our pricing and support are unrivaled, especially when compared to other Competitors.
