SRH2-1215: Autonics 12V 15A SSR Relay
Technical Specifications of Autonics 12V 15A SSR Relay SRH2-1215
| Spec | Value |
|---|---|
| Control phase | 2-Phase |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 4-30VDC |
| Rated load current | 15A |
Autonics 12V 15A SSR Relay SRH2-1215 Technical Specifications:
| Specification | Value |
|---|---|
| Control phase | 2-Phase |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 4-30VDC |
| Rated load voltage | 24-240VAC~ |
| Dielectric strength | 2,500VAC~ |
| Rated load current | 15A |
| Function | Zero cross turn-on |
| Environment_Ambient temperature | -30 to 80℃(in case of the rated input voltage 90-240VAC~: -30 to 70℃), Storage: -30 to 100℃( The rated load current capacity is different depending on ambient temperature. Refer to '▣ SSR Derating Curve'.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | approx. 896g(approx. 686g) |
Mail Us for your needs in Autonics 12V 15A SSR Relay SRH2-1215 with budget-friendly prices. The Main Technical Parameters of SRH2-1215 include 2-Phase, Panel, DIN rail mounting, 4-30VDC input voltage, 24-240VAC~ load voltage, 15A load current, Zero cross turn-on function. Customize Your Experience with a Quote for your requirement of Autonics 12V 15A SSR Relay. Experience the difference with our competitive pricing and superior support over other Suppliers.
