SRH2-4450: Autonics 2-pole Solid State Relay
Technical Specifications of Autonics 2-pole Solid State Relay SRH2-4450
Spec | Value |
---|---|
Control phase | 2-Phase |
Mounting type | Panel, DIN rail |
Rated input voltage | 90-240VAC~ |
Rated load current | 50A |
Autonics 2-pole Solid State Relay SRH2-4450 Technical Specifications:
Specification | Value |
---|---|
Control phase | 2-Phase |
Mounting type | Panel, DIN rail |
Rated input voltage | 90-240VAC~ |
Rated load voltage | 48-480VAC~ |
Dielectric strength | 4,000VAC~ |
Rated load current | 50A |
Function | Zero cross turn-on |
Environment_Ambient temperature | -30 to 80℃(in case of the rated input voltage 90-240VAC~: -30 to 70℃), Storage: -30 to 100℃( The rated load current capacity is different depending on ambient temperature. Refer to '▣ SSR Derating Curve'.) |
Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
Weight | approx. 1508g(approx. 1268g) |
Ask for the Pricing of Autonics 2-pole Solid State Relay SRH2-4450 at unbeatable prices. Detailed Specifications of SRH2-4450 features 2-Phase, Panel, DIN rail mounting, 90-240VAC~ input voltage, 48-480VAC~ load voltage, 50A load current, Zero cross turn-on function. Now's the Time to Secure a Quote for your requirement of Autonics 2-pole Solid State Relay. We're committed to offering more favorable pricing and more responsive support than other Traders.
