SRH3-2450: Autonics 50A 3-phase Solid State Relay
Technical Specifications of Autonics 50A 3-phase Solid State Relay SRH3-2450
| Spec | Value |
|---|---|
| Control phase | 3-Phase |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 24VAC~ |
| Rated load current | 50A |
Autonics 50A 3-phase Solid State Relay SRH3-2450 Technical Specifications:
| Specification | Value |
|---|---|
| Control phase | 3-Phase |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 24VAC~ |
| Rated load voltage | 48-480VAC~ |
| Dielectric strength | 4,000VAC~ |
| Rated load current | 50A |
| Function | Zero cross turn-on |
| Environment_Ambient temperature | -30 to 80℃(in case of the rated input voltage 90-240VAC~: -30 to 70℃), Storage: -30 to 100℃( The rated load current capacity is different depending on ambient temperature. Refer to '▣ SSR Derating Curve'.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | approx. 1508g(approx. 1268g) |
Give Us a Call for Autonics 50A 3-phase Solid State Relay SRH3-2450 at the lowest pricing. In-depth Technical Analysis of SRH3-2450 feature 3-Phase, Panel, DIN rail mounting, 24VAC~ input voltage, 48-480VAC~ load voltage, 50A load current, Zero cross turn-on function. Elevate Your Project with a Quote for your requirement of Autonics 50A 3-phase Solid State Relay. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
