Autonics SRH3-4450 - 3-Phase SSR Integrated Heatsink Type
Technical Specifications of Autonics 3-Phase SSR Integrated Heatsink Type SRH3-4450:
| Spec | Value |
|---|
| Control phase | 3-phase |
| Mounting type | Panel, DIN rail |
| Rated load voltage | 48-480VAC~ |
| Rated load current | 50A |
Autonics 3-Phase SSR Integrated Heatsink Type SRH3-4450 Technical Specifications
| Specification | Value |
|---|
| Control phase | 3-phase |
| Heatsink | Heatsink |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 90-240VAC~ |
| Rated load voltage | 48-480VAC~ |
| Dielectric strength | 4,000VAC~ |
| Rated load current | 50A |
| Function | Zero cross turn-on |
| Environment_Ambient temperature | -30 to 80℃(in case of the rated input voltage 90-240VAC~: -30 to 70℃), Storage: -30 to 100℃( The rated load current capacity is different depending on ambient temperature. Refer to '▣ SSR Derating Curve'.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | approx. 1508g(approx. 1268g) |
