SRHL1-4420: Autonics 20Amp DIN Rail SSR
Technical Specifications of Autonics 20Amp DIN Rail SSR SRHL1-4420
| Spec | Value |
|---|---|
| Control phase | Single-phase |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 90-240VAC~ |
| Rated load current | 20A |
Autonics 20Amp DIN Rail SSR SRHL1-4420 Technical Specifications:
| Specification | Value |
|---|---|
| Control phase | Single-phase |
| Mounting type | Panel, DIN rail |
| Rated input voltage | 90-240VAC~ |
| Rated load voltage | 48-480VAC~ |
| Dielectric strength | • Input-output: 2500VAC 50/60Hz for 1 min, • Input/output-case: 4000VAC 50/60Hz for 1 min |
| Rated load current | 20A |
| Function | Zero cross turn-on |
| Environment_Ambient temperature | -30 to 70℃, storage: -30 to 100℃ (The rated load current capacity is different depending on ambient temperature. Refer to '▣ SSR Derating Curve'.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | Approx. 270g(approx.192g) |
Talk to Our Engineer for Autonics 20Amp DIN Rail SSR SRHL1-4420 with exclusive offers. Core System Specifications of SRHL1-4420 are Single-phase, Panel, DIN rail mounting, 90-240VAC~ input voltage, 48-480VAC~ load voltage, 20A load current, Zero cross turn-on function. Don't Miss Out on a Quote for your requirement of Autonics 20Amp DIN Rail SSR. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
