Autonics SRS1-C1205R-1 - Single-Phase Solid State Relays
Technical Specifications of Autonics Single-Phase Solid State Relays SRS1-C1205R-1:
| Spec | Value |
|---|
| Control Phase | Single-phase |
| Rated Input Voltage | 4-30VDC @(=) |
| Rated Load Voltage | 90-240VAC~ (50/60Hz) |
Autonics Single-Phase Solid State Relays SRS1-C1205R-1 Technical Specifications
| Specification | Value |
|---|
| Control phase | Single-phase |
| Rated input voltage | 4-30VDC @(=) |
| Rated load voltage | 90-240VAC~ (50/60Hz) |
| Dielectric strength | 2,500VAC~ |
| Rated load current | 5A |
| Function | Random turn-on |
| Socket | Universal MY4 socket |
| Number of output circuits | 1 EA |
| Environment_Ambient temperature | -20 to 80℃, storage: -30 to 100℃(The rated load current capacity is different depending on ambient temperature. Refer to ‘▣ SSR Derating Curve’.) |
| Environment_Ambient humidity | 45 to 85% RH, storage: 45 to 85% RH |
| Weight | Approx. 400g(approx. 30g) |
