Banner Photoelectric Sensor – Reflective & Diffuse Sensors
Banner Photoelectric Sensors are used in industrial automation to detect objects using light without physical contact. They are widely used in conveyors, packaging machines, assembly lines, and object detection systems where fast and accurate sensing is required. Choosing the right Photoelectric Sensor helps improve efficiency and reduce errors in these applications.
Banner is known for delivering reliable and high-performance sensing solutions for industrial environments. With strong support from Banner Photoelectric Sensor Dealers and Distributors, these sensors offer stable detection, quick response, and long-term durability. On IndMALL, you can find Banner Photoelectric Sensor and connect with verified suppliers across India for your requirements.
Banner Photoelectric Sensor Series
Banner Photoelectric Sensor –Β QS18 Series
- Performance: Versatile sensing with up to 20 meters range.
- Design: Universal 18 mm threaded housing, suitable for diverse applications.
- Durability: IP67 and NEMA 6 are rated for tough environments.
- Indicators: 360Β° visible LED status lights.
- Connectivity: IO-Link communication in some models for better integration.
Banner Retroreflective Sensor – Q4X Series
- Performance: Capable of detecting sub-millimeter changes in distance.
- Range: Reliable sensing from 25 mm to 610 mm.
- Versatility: Detects across various target colors, materials, and surfaces.
- Durability: IP69K rated with FDA-grade stainless steel housing.
Banner Diffuse Sensor – S18 Series
- Design: Compact with 18 mm threaded plastic barrels.
- Sensing Modes: Multiple modes including retroreflective, diffuse, and fixed-field.
- Laser Option: Specialized models with laser diode emitters.
- Power Compatibility: Operates on both AC and DC power sources.
Banner Photo Sensor – Q60 Series
- Sensing Range: Adjustable from 0.2 to 2 meters.
- Beam Options: Infrared, visible red LED, or laser beams.
- Adjustment: Logarithmic two-turn for precise cutoff setting.
- Power Options: 10 to 30V DC, bipolar NPN/PNP, or 12 to 250V AC with relay output.
- Programming: Simple push-button or remote setup.
Banner Reflective Sensor – S18-2 Series
- Models: Variety including Emitter/Receiver and Retroreflective types.
- Temperature Range: Operates from -40 to +70Β° C.
- Sensitivity: 250Β° potentiometer for precise adjustments.
- Design: Durable ABS plastic housing.
- Power: 10-30 V DC with NPN/PNP outputs.
Banner Photoelectric VS8 Series
- Design: Miniature size for tight spaces.
- Light Source: Red laser, Red LED, and Blue LED options.
- Detection: Precise targeting, suitable for small parts.
- Frequency: High switching frequency for rapid processes.
- Operation: Easy use with push button or remote input.
- Output: PNP or NPN options available.
Banner Photo Sensors – QS30 Series
- Performance: High-power sensing with up to 200 meters range.
- Design: Versatile 30 mm housing for various mounting needs.
- Power Options: 10 to 30V DC with bipolar outputs or 24 to 250V AC with relay output.
- Functionality: Selectable light/dark operation modes.
- Environmental Rating: IP67 or IP69K, depending on the model.
Banner Q45 Series
- Durability: Exceeds NEMA 6P and IEC IP67 standards, suitable for high-pressure washdowns.
- Indicators: LED indicators for Power, Signal, and Output.
- Sensing Modes: Includes opposed, retroreflective, diffuse, convergent, and laser modes.
- Power Options: Available for DC, AC, and universal voltage power.
Banner Photoelectric Sensor Suppliers
Top Banner Photoelectric Sensor Models
| Model No | Image | IP Rating | Sensing Beam | Max Sensing Distance (mm) | Connection | Number of Pins |
|---|---|---|---|---|---|---|
| S18-2VPDS-2M |
|
IP67 | Visible Red LED | 300 | Cable | 4 |
| QS186EV |
|
IP67 | Visible Red LED | 20000 | Cable | 2 |
| Q4XTBLAF300-Q8 |
|
IP67, IP68, IP69K | Visible Red Laser | 300 | Integral QD | 5 |
| QS30EXQ |
|
IP69K | Infrared LED | 213000 | Integral QD | 5 |
| S186EQ |
|
IP67, IP69K | Infrared LED | 20000 | Integral QD | 4 |
βAt IndMALL Automation, we specialize in offering Banner Photoelectric Sensors, renowned for their precision and reliability in industrial applications. Our extensive range includes Banner Photo Sensors, Banner Reflective Sensors, and other advanced options designed to meet diverse industrial requirements.
Whether you need Banner Retro Reflective Sensors for detecting reflective surfaces or Banner Diffuse Sensors for direct object detection, we have the ideal solution for your application. For tasks requiring high accuracy, our Banner Through Beam Sensors and Banner Optical Sensors deliver exceptional performance.
Explore our complete Banner Photoelectric Sensors catalog to find the right fit for your needs. Learn about the Banner Photo Sensor working principle, download the Banner Photo Sensor PDF, or refer to the Banner Photo Eye Manual for detailed guidance. Contact us today for the best Banner Photo Sensor price, and let us help you optimize your process automation with industry-leading sensors.
Banner Photoelectric Sensor FAQs
What is the range of the banner Q4X?
The Banner Q4X sensor has a range that varies. It can sense objects from as close as 25 mm away. It can also detect objects up to 610 mm away.
This makes the Q4X versatile for different uses. Its range is suitable for various industrial tasks. Whether close-up or at a distance, the Q4X works reliably.
What type of light is a photoelectric sensor?
A photoelectric sensor uses light to detect objects. It sends out a beam of light, which can be visible or invisible. When this light hits an object, it reflects back to the sensor. The sensor then knows there’s something there. This type of light is often an LED or a laser.
LED light is common and works well for many situations. Lasers are used for precise detection. They are great for spotting small or far-away things. This light-based technology is very useful in many machines and systems.
Is IR sensor a photoelectric sensor?
Yes, an IR sensor is a type of photoelectric sensor. It uses infrared (IR) light to detect objects. This light is invisible to our eyes.
When the IR light hits something, it bounces back to the sensor. The sensor then reacts to this reflected light.
IR sensors are used in many devices. For example, they are in TV remotes and automatic doors. They help in sensing the presence or distance of objects.
This makes IR sensors very useful in various applications. They are especially good where visible light might be disruptive.
We are dedicated to helping you select the ideal Banner Photoelectric Sensor for your industrial needs.
