a2A2590 (IMX334ROI): 108030 - Basler 6.5 mm Sensor Diagonal Vision System
Technical Specifications of Basler 6.5 mm Sensor Diagonal Vision System a2A2590 (IMX334ROI) 108030:
| Spec | Value |
|---|---|
| Product Family | ace 2 R |
| Frame rate | 22 fps |
| Interface | GigE |
| Pixel Bit Depth | 8 bits, 10 bits, 12 bits |
Basler 6.5 mm Sensor Diagonal Vision System a2A2590 (IMX334ROI), 108030 Technical Specifications:
| Specification | Value |
|---|---|
| Product Family | ace 2 R |
| Camera Category | Area Scan Camera |
| Sensor Vendor | Sony |
| Sensor | IMX334ROI |
| Shutter | Rolling Shutter |
| Sensor Format | 1/2.5" |
| Sensor Diagonal | 6.5 mm |
| Sensor Type | CMOS |
| Sensor Size | 5.2 mm × 3.9 mm |
| Resolution (H x V) | 2592 px × 1944 px |
| Resolution | 5 MP |
| Pixel Size (H x V) | 2 μm × 2 μm |
| Frame rate | 22 fps |
| Mono/Color | Mono |
| Spectrum | Visible |
| Quantum Efficiency (typical/minimal) | 72.9 % (typical) |
| Dark Noise (typical/maximal) | 1.96 e¯ (typical) |
| Saturation Capacity (typical/minimal) | 7.2 ke¯ (typical) |
| Dynamic Range (typical/minimal) | 69.2 dB (typical) |
| Signal-to-Noise Ratio (typical/minimal) | 38.6 dB (typical) |
| Interface | GigE |
| Image Data Interface | Fast Ethernet (100 Mbit/s), Gigabit Ethernet (1000 Mbit/s) |
| Pixel Bit Depth | 8 bits, 10 bits, 12 bits |
| Exposure Control | hardware trigger, programmable via the camera API |
| Digital Input | 1 |
| Power Supply | PoE or 12-24 VDC |
| Power Requirements (typical) | 2.5 W |
| Housing Type | Box |
| Housing Size (L x W x H) | 55.5 mm x 29 mm x 29 mm |
| Weight | 100 g |
| Lens Mount | C-mount |
| Operating Temperature | -10 °C - 60 °C |
| Attribute Name | Attribute Value |
| Mount | C-mount |
| Focal Length | 4 mm |
| Working Distance | 100 mm |
| Type | Lens Accessory |
| Cable Length | 5 m |
| LED Color | Red |
| Peak Wavelength (typical) | 625 nm |
| Protection Class | IP54 |
| Product Line | Standard |
| No. of Ports | 4 |
| Data Bandwidth (p.port; Total) | 1 Gbps; 4 Gbps |
Give Us a Call for Basler 6.5 mm Sensor Diagonal Vision System a2A2590 (IMX334ROI) part no: 108030 at the lowest pricing. In-depth Technical Analysis of a2A2590 (IMX334ROI), 108030 feature ace 2 R Sensor Product Family offers a cutting-edge 5 MP resolution at an impressive 22 fps utilizing the GigE interface. It supports 8 bits, 10 bits, 12 bits pixel depth, ensuring high-quality imaging. Power is supplied via PoE or 12-24 VDC, making it efficient and easy to integrate. The robust Box-type housing is designed to withstand industrial conditions, with an C-mount lens interface for versatile application. Operating temperatures range from -10 °C - 60 °C making it reliable in various environments. The system is equipped with a 4 mm focal length lens, a working distance of 100 mm and a cable length of 5 m providing flexibility for different setups. The sensor operates at a peak wavelength of 625 nm. Elevate Your Project with a Quote for your requirement of Basler 6.5 mm Sensor Diagonal Vision System. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
