boA4096-180cm: 108668 - Basler 180 fps Frame Rate Vision System
Technical Specifications of Basler 180 fps Frame Rate Vision System boA4096-180cm 108668:
| Spec | Value |
|---|---|
| Resolution | 12 MP |
| Pixel Size (H x V) | 2.74 μm × 2.74 μm |
| Frame rate | 180 fps |
| Power Supply | PoCXP or 24 VDC |
Basler 180 fps Frame Rate Vision System boA4096-180cm, 108668 Technical Specifications:
| Specification | Value |
|---|---|
| Product Family | boost R |
| Camera Category | Area Scan Camera |
| Sensor Vendor | Sony |
| Sensor | IMX535 |
| Shutter | Global Shutter |
| Sensor Format | 2/3" |
| Sensor Diagonal | 13.9 mm |
| Sensor Type | CMOS |
| Sensor Size | 11.2 mm × 8.2 mm |
| Resolution (H x V) | 4096 px × 3000 px |
| Resolution | 12 MP |
| Pixel Size (H x V) | 2.74 μm × 2.74 μm |
| Frame rate | 180 fps |
| Mono/Color | Mono |
| Spectrum | Visible |
| Interface | CoaXPress (CXP-12) |
| Image Data Interface | CoaXPress (2.5–12.5 Gbps) |
| General Purpose I/O | 2 |
| Power Supply | PoCXP or 24 VDC |
| Housing Size (L x W x H) | 45 mm x 80 mm x 80 mm |
| Weight | 525 g |
| Attribute Name | Attribute Value |
| Type | Lens Accessory |
| Cable Length | 5 m |
| LED Color | Red |
| Peak Wavelength (typical) | 625 nm |
| Protection Class | IP54 |
| Product Line | Standard |
| No. of Ports | 4 |
| Data Bandwidth (p.port; Total) | 12.5 Gbps; 50 Gbps |
| Pixel Bit Depth | 8 bits, 10 bits, 12 bits |
| Synchronization | free-run, hardware trigger, software trigger |
| Digital Output | 1 |
| Power Requirements (typical) | 12 W |
| Housing Type | Box |
| Operating Temperature | 0 °C - 50 °C |
| Mount | C-mount |
| Focal Length | 16 mm |
| Working Distance | 200 mm |
| Exposure Control | hardware trigger, programmable via the camera API |
| Lens Mount | C-mount, F-mount, M42 x 0.75, M42 x 1 |
Mail Us for your needs in Basler 180 fps Frame Rate Vision System boA4096-180cm part no: 108668 with budget-friendly prices. The Main Technical Parameters of boA4096-180cm, 108668 inludce boost R Product Family 12 MP resolution with a pixel size of 2.74 μm × 2.74 μm. This camera supports a frame rate of 180 fps and utilizes the CoaXPress (CXP-12) interface for high-speed data transmission. Powered by PoCXP or 24 VDC it ensures reliable operation. The compact housing measures 45 mm x 80 mm x 80 mm making it suitable for various applications. It comes with a standard 5 m and Lens Accessory and operates at a peak wavelength of 625 nm. The product line includes 4 housed in a robust Box-type enclosure designed to withstand temperatures up to 0 °C - 50 °C. Customize Your Experience with a Quote for your requirement of Basler 180 fps Frame Rate Vision System. Experience the difference with our competitive pricing and superior support over other Suppliers.
