MAGRES EAM580-K - SSI: Baumer Magnetic Encoder
Technical Specifications of Baumer Magnetic Encoder MAGRES EAM580-K - SSI:
| Spec | Value |
|---|---|
| Voltage Supply | 4.5…30 VDC (SSI, SSI + TTL/RS422), 5.5…30 VDC (SSI + HTL/Push-pull) |
| Interface | SSI, SSI + incremental |
| Shaft type | ø6 mm (magnet bore), ø8 mm (magnet bore), ø12 mm (magnet bore) |
| Connection | Flange connector M12, 8-pin, Flange connector M12, 12-pin, Cable 2 m |
Baumer Magnetic Encoder MAGRES EAM580-K - SSI Technical Specifications:
| Specification | Value |
|---|---|
| Voltage supply | 4.5…30 VDC (SSI, SSI + TTL/RS422), 5.5…30 VDC (SSI + HTL/Push-pull) |
| Reverse polarity protection | |
| Consumption w/o load | |
| Interface | SSI, SSI + incremental |
| Function | Multiturn, Singleturn |
| Total resolution | |
| Absolute accuracy | ±0.15 ° (+20 ±15 °C), ±0.25 ° (-40...+85 °C) |
| Sensing method | Magnetic |
| Status indicator | |
| Size (flange) | ø58 mm |
| Shaft type | ø6 mm (magnet bore), ø8 mm (magnet bore), ø12 mm (magnet bore) |
| Protection EN 60529 | IP 67 |
| Operating speed | ≤6000 rpm |
| Starting acceleration | |
| Starting torque | |
| Rotor moment of inertia | |
| Material | Housing: steel zinc-coated, Flange: aluminium |
| Operating temperature | -40...+85 °C (see general information) |
| Relative humidity | 95 % |
| Resistance | EN 60068-2-6, Vibration 30 g, 10-2000 Hz, EN 60068-2-27, Shock 500 g, 1 ms |
| Weight approx. | 250 g |
| Connection | Flange connector M12, 8-pin, Flange connector M12, 12-pin, Cable 2 m |
Mail Us for your needs in Baumer Magnetic Encoder MAGRES EAM580-K - SSI with budget-friendly prices. The Main Technical Parameters of MAGRES EAM580-K - SSI, inludce voltage supply of 4.5…30 VDC (SSI, SSI + TTL/RS422), 5.5…30 VDC (SSI + HTL/Push-pull). These encoders feature the SSI, SSI + incremental interface, Multiturn, Singleturn functionality, and Magnetic sensing methods for accurate performance. The flange size is ø58 mm, making them suitable for various industrial applications. The operating speed reaches up to ≤6000 rpm operations, ensuring reliable functionality in demanding environments. The Housing: steel zinc-coated, Flange: aluminium, provides robust protection. The connection is facilitated by Flange connector M12, 8-pin, Flange connector M12, 12-pin, Cable 2 m, ensuring secure and efficient data transmission. Customize Your Experience with a Quote for your requirement of Baumer Magnetic Encoder For Precision. Experience the difference with our competitive pricing and superior support over other Suppliers.
