O300.ZL-GW1J.72CU: 11176829 - Baumer Sensor With Intensity Difference Detection
Technical Specifications of Baumer Sensor With Intensity Difference Detection O300.ZL-GW1J.72CU 11176829:
| Spec | Value |
|---|---|
| Sensing distance Tw | 10 … 250 mm |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Connection types | Cable 4 pin, 2 m |
Baumer Sensor With Intensity Difference Detection O300.ZL-GW1J.72CU, 11176829 Technical Specifications:
| Specification | Value |
|---|---|
| Type | Intensity difference |
| Sensing distance Tw | 10 … 250 mm |
| Repeat accuracy | < 0.1 mm at laser focus |
| Power on indication | LED green |
| Light indicator | LED yellow |
| Sensing distance adjustment | Teach-in and IO-Link |
| Distance to focus | 80 mm |
| Alignment optical axis | < 2° |
| Light source | Pulsed red laser diode |
| Laser class | 1 |
| Wave length | 656 nm |
| Response time / release time | < 0.1 ms |
| Voltage supply range +Vs | 11 … 30 VDC |
| Current consumption max. (no load) | 30 mA |
| Current consumption typ. | 25 mA |
| Voltage drop Vd | <2.5 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Protection class | IP 67 |
| Operating temperature | -10 … +60 °C |
Get A Quote for Baumer Sensor With Intensity Difference Detection O300.ZL-GW1J.72CU part no: 11176829 at the best price. Here are the brief Technical Specifications of O300.ZL-GW1J.72CU, 11176829 are Intensity difference Sensor, engineered for precise detection with a sensing distance of 10 … 250 mm. The sensor utilizes a Pulsed red laser diode with a wavelength of 656 nm, ensuring accurate and rapid response times of less than < 0.1 ms. It operates within a voltage supply range of 11 … 30 VDC, offering Light / dark operate functionality with a Push-pull output circuit capable of handling up to 100 mA of output current. Measuring 12.9 mm in width and 32.3 mm in height, the compact Rectangular design is housed in durable Plastic (ASA, PMMA) materials. The connection is made via a Cable 4 pin, 2 m. It's Time to get a Quote for your requirement of Baumer Sensor With Intensity Difference Detection. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
