optoPulse EIL580-B: Baumer Incremental Encoder With Blind Hollow Shaft
Technical Specifications of Baumer Incremental Encoder With Blind Hollow Shaft optoPulse EIL580-B:
| Spec | Value |
|---|---|
| Voltage supply | 5 VDC ±5 %, 8...30 VDC, 4.75...30 VDC |
| Sensing method | Optical |
| Size (flange) | ø58 mm |
| Connection | Flange connector M12, 8-pin, Flange connector M23, 12-pin, Cable |
Baumer Incremental Encoder With Blind Hollow Shaft optoPulse EIL580-B Technical Specifications:
| Specification | Value |
|---|---|
| Voltage supply | 5 VDC ±5 %, 8...30 VDC, 4.75...30 VDC |
| Consumption w/o load | ≤70 mA |
| Pulses per revolution | 100 … 5000 |
| Phase shift | 90 ° ±10° |
| Duty cycle | 40…60 % |
| Reference signal | Zero pulse, width 90° ±10 % |
| Sensing method | Optical |
| Output frequency | ≤300 kHz (TTL), ≤160 kHz (HTL) |
| Output signals | A+, B+, R+, A-, B-, R- |
| Output stages | TTL/RS422, HTL/push-pull |
| Size (flange) | ø58 mm |
| Shaft type | ø8...15 mm (blind hollow shaft), ø9.52 mm (blind hollow shaft), ø12.7 mm (blind hollow shaft) |
| Protection EN 60529 | IP 65 (without shaft seal), IP 67 (with shaft seal) |
| Operating speed | ≤6000 rpm (+20 °C, IP 67), ≤8000 rpm (+20 °C, IP 65) |
| Starting torque | ≤0.02 Nm (+20 °C, IP 65), ≤0.025 Nm (+20 °C, IP 67) |
| Material | Housing: aluminium die-cast, Flange: aluminium |
| Operating temperature | -40...+85 °C |
| Relative humidity | 90 % non-condensing |
| Resistance | EN 60068-2-6, Vibration 30 g, 10-2000 Hz, EN 60068-2-27, Shock 250 g, 6 ms |
| Connection | Flange connector M12, 8-pin, Flange connector M23, 12-pin, Cable |
| Weight approx. | 300 g |
Get A Quote for Baumer Incremental Encoder With Blind Hollow Shaft optoPulse EIL580-B at the best price. Here are the brief Technical Specifications of optoPulse EIL580-B are voltage supply of 5 VDC ±5 %, 8...30 VDC, 4.75...30 VDC and a low power consumption of ≤70 mA without load. These encoders use Optical sensing for accurate measurement and provide output frequencies of ≤300 kHz (TTL), ≤160 kHz (HTL). The available output stages include TTL/RS422, HTL/push-pull. The encoders feature a ø58 mm flange size and operate at speeds of up to ≤6000 rpm (+20 °C, IP 67), ≤8000 rpm (+20 °C, IP 65). The Housing: aluminium die-cast, Flange: aluminium. Connection options include Flange connector M12, 8-pin, Flange connector M23, 12-pin, Cable. The approximate weight is 300 g. It's Time to get a Quote for your requirement of Baumer Incremental Encoder With Blind Hollow Shaft. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
