optoPulse EN580E.IL-TT14.GE1T2.02048.K: 11246000 - Baumer Flylead Connector
Technical Specifications of Baumer Flylead Connector optoPulse EN580E.IL-TT14.GE1T2.02048.K:
| Spec | Value |
|---|---|
| Voltage supply | 5 VDC ±5 % |
| Sensing method | Optical |
| Size (flange) | ø58 mm |
| Connection | Flylead connector M23, 12-pin, tangential, length 300 mm |
Baumer Flylead Connector optoPulse EN580E.IL-TT14.GE1T2.02048.K 11246000 Technical Specifications:
| Specification | Value |
|---|---|
| Voltage supply | 5 VDC ±5 % |
| Consumption w/o load | ≤70 mA |
| Pulses per revolution | 2048 |
| Phase shift | 90 ° ±10° |
| Duty cycle | 40…60 % |
| Reference signal | Zero pulse, width 90° ±10 % |
| Sensing method | Optical |
| Output frequency | ≤300 kHz (TTL) |
| Output signals | A+, B+, R+, A-, B-, R- |
| Output stages | TTL/RS422 |
| Size (flange) | ø58 mm |
| Shaft type | ø14 mm (through hollow shaft) |
| Protection EN 60529 | IP 54 (flange side), IP 65 (housing side) |
| Operating speed | ≤6000 rpm (+25 °C) |
| Starting torque | ≤0.04 Nm |
| Material | Housing: aluminium, Solid shaft: stainless steel |
| Operating temperature | -25...+100 °C (see general information) |
| Relative humidity | 95 % non-condensing |
| Resistance | EN 60068-2-6 Vibration 10 g, 10-2000 Hz, EN 60068-2-27 Shock 100 g, 11 ms |
| Connection | Flylead connector M23, 12-pin, tangential, length 300 mm |
| Weight approx. | 300 g |
Ask for the Pricing of Baumer Flylead Connector optoPulse EN580E.IL-TT14.GE1T2.02048.K part no: 11246000 at unbeatable prices. Detailed Specifications of optoPulse EN580E.IL-TT14.GE1T2.02048.K, 11246000 feature voltage supply of 5 VDC ±5 % and a low power consumption of ≤70 mA without load. These encoders use Optical sensing for accurate measurement and provide output frequencies of ≤300 kHz (TTL). The available output stages include TTL/RS422. The encoders feature a ø58 mm flange size and operate at speeds of up to ≤6000 rpm (+25 °C). The Housing: aluminium, Solid shaft: stainless steel. Connection options include Flylead connector M23, 12-pin, tangential, length 300 mm. The approximate weight is 300 g. Now's the Time to Secure a Quote for your requirement of Baumer Flylead Connector. We're committed to offering more favorable pricing and more responsive support than other Traders.
