OR18.ZI-PW1Z.71CV/B013: 11157795 - Baumer Sensor With LED Output Indicator
Technical Specifications of Baumer Sensor With LED Output Indicator OR18.ZI-PW1Z.71CV/B013 11157795:
| Spec | Value |
|---|---|
| Sensing distance Tw | < 300 mm |
| Output function | Light / dark operate |
| Output circuit | PNP |
| Connection types | Cable 4 pin, 2 m |
Baumer Sensor With LED Output Indicator OR18.ZI-PW1Z.71CV/B013, 11157795 Technical Specifications:
| Specification | Value |
|---|---|
| Type | Intensity difference |
| Sensing distance Tw | < 300 mm |
| Sensing distance adjustment | No |
| Light source | Pulsed infrared diode |
| Wave length | 880 nm |
| Response time / release time | < 1 ms |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | PNP |
| Output current | 100 mA |
| Width / diameter | 18 mm |
| Height / length | 44.8 mm |
| Design | Cylindrical threaded |
| Housing material | Plastic (ABS TERLURAN) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Protection class | IP 67 |
| Operating temperature | -25 … +55 °C |
| Alignment / soiled lens indicator | LED green |
| Output indicator | LED yellow |
Talk to Our Engineer for Baumer Sensor With LED Output Indicator OR18.ZI-PW1Z.71CV/B013 part no: 11157795 with exclusive offers. Core System Specifications of OR18.ZI-PW1Z.71CV/B013, 11157795 are Intensity difference Sensor, engineered for precise detection with a sensing distance of < 300 mm. The sensor utilizes a Pulsed infrared diode with a wavelength of 880 nm, ensuring accurate and rapid response times of less than < 1 ms. It operates within a voltage supply range of 12 … 30 VDC, offering Light / dark operate functionality with a PNP output circuit capable of handling up to 100 mA of output current. Measuring 18 mm in width and 44.8 mm in height, the compact Cylindrical threaded design is housed in durable Plastic (ABS TERLURAN) materials. The connection is made via a Cable 4 pin, 2 m. Don't Miss Out on a Quote for your requirement of Baumer Sensor With LED Output Indicator. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
