OR18.ZI-PW1Z.71OV/0010_B012: 11157791 - Baumer Photoelectric Sensor With PNP Output
Technical Specifications of Baumer Photoelectric Sensor With PNP Output OR18.ZI-PW1Z.71OV/0010_B012 11157791:
| Spec | Value |
|---|---|
| Sensing distance Tw | < 80 mm |
| Output function | Light / dark operate |
| Output circuit | PNP |
| Connection types | Flylead connector M12 4 pin, L=100 mm |
Baumer Photoelectric Sensor With PNP Output OR18.ZI-PW1Z.71OV/0010_B012, 11157791 Technical Specifications:
| Specification | Value |
|---|---|
| Type | Intensity difference |
| Sensing distance Tw | < 80 mm |
| Sensing distance adjustment | No |
| Light source | Pulsed infrared diode |
| Wave length | 880 nm |
| Response time / release time | < 1 ms |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | PNP |
| Output current | 100 mA |
| Width / diameter | 18 mm |
| Height / length | 44.8 mm |
| Design | Cylindrical threaded |
| Housing material | Plastic (ABS TERLURAN) |
| Front (optics) | PMMA |
| Connection types | Flylead connector M12 4 pin, L=100 mm |
| Protection class | IP 67 |
| Operating temperature | -25 … +55 °C |
| Alignment / soiled lens indicator | LED green |
| Output indicator | LED yellow |
Give Us a Call for Baumer Photoelectric Sensor With PNP Output OR18.ZI-PW1Z.71OV/0010_B012 part no: 11157791 at the lowest pricing. In-depth Technical Analysis of OR18.ZI-PW1Z.71OV/0010_B012, 11157791 feature Intensity difference Sensor, engineered for precise detection with a sensing distance of < 80 mm. The sensor utilizes a Pulsed infrared diode with a wavelength of 880 nm, ensuring accurate and rapid response times of less than < 1 ms. It operates within a voltage supply range of 12 … 30 VDC, offering Light / dark operate functionality with a PNP output circuit capable of handling up to 100 mA of output current. Measuring 18 mm in width and 44.8 mm in height, the compact Cylindrical threaded design is housed in durable Plastic (ABS TERLURAN) materials. The connection is made via a Flylead connector M12 4 pin, L=100 mm. Elevate Your Project with a Quote for your requirement of Baumer Photoelectric Sensor With PNP Output. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
