OT300.SL-NDNVT.72CU: 11250347 - Baumer Dark Operate Smartreflective Sensor
Technical Specifications of Baumer Dark Operate Smartreflective Sensor OT300.SL-NDNVT.72CU 11250347:
| Spec | Value |
|---|---|
| Type | Light barrier |
| Scanning range Sa | 85% ... 80% Sde |
| Output circuit | NPN |
| Connection types | Connector M8 4 pin |
Baumer Dark Operate Smartreflective Sensor OT300.SL-NDNVT.72CU, 11250347 Technical Specifications:
| Specification | Value |
|---|---|
| Type | Light barrier |
| Version | Time of Flight |
| Background position Sde | |
| Scanning range Sa | 85% ... 80% Sde |
| Smallest object recognizable typ. | |
| Power on indication | LED green |
| Alignment / soiled lens indicator | |
| Output indicator | LED yellow |
| Sensing distance adjustment | qTeach |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 2° |
| Light source | Pulsed red laser diode |
| Wave length | 680 nm |
| Response time / release time | < 8 ms |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption max. (no load) | 60 mA |
| Current consumption typ. | |
| Voltage drop Vd | <2 VDC |
| Output function | Dark operate, complementary |
| Output circuit | NPN |
| Output current | 50 mA, sum of all outputs |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Design | Rectangular |
| Mechanical mounting | |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Connector M8 4 pin |
| Cable characteristics | |
| Protection class | IP 67 |
| Operating temperature | -20 … +50 °C |
Mail Us for your needs in Baumer Dark Operate Smartreflective Sensor OT300.SL-NDNVT.72CU part no: 11250347 with budget-friendly prices. The Main Technical Parameters of OT300.SL-NDNVT.72CU, 11250347 inludce Light barrier, Type offering superior precision and reliability. This sensor features a scanning range (Sa) 85% ... 80% Sde with adjustable sensing distance qTeach. It operates using a Pulsed red laser diode light source with a wave length of 680 nm. The voltage supply range is 12 … 30 VDC, with a current consumption of 60 mA. The voltage drop (Vd) is less than <2 VDC, with Dark operate, complementary output functions. The output circuit is NPN, and the output current is rated at 50 mA, sum of all outputs. With a width of 12.9 mm and a height of 32.3 mm, the housing is made of durable Plastic (ASA, PMMA). This sensor is equipped with a Connector M8 4 pin connection. Customize Your Experience with a Quote for your requirement of Baumer Dark Operate Smartreflective Sensor. Experience the difference with our competitive pricing and superior support over other Suppliers.
