OXS200-B02A.E02: 11728848 - Baumer Smart Vision Sensor Solutions
Technical Specifications of Baumer Smart Vision Sensor Solutions OXS200-B02A.E02 11728848:
Spec | Value |
---|---|
Dimensions (W x H x D) | 36 mm x 74 mm x 60 mm |
Measurement range MR | 25 mm |
Switching outputs | 2 x Outputs (Push-Pull) |
Electrical connection | M12, 12-pin, A-coded, male |
Baumer Smart Vision Sensor Solutions OXS200-B02A.E02, 11728848 Technical Specifications:
Specification | Value |
---|---|
Measurement range MR | 25 mm |
Clearance distance | 60 mm |
Working range (Sdc ... Sde) | 60 ... 85 mm |
Reference distance | 72.5 mm |
Field of view (@Sdc ... Sde) | 20 mm ... 28 mm |
Resolution X (@Sdc ... Sde) | 30 ... 40 µm |
Profiles per second | 100 ... 400 Hz |
Profile points | 700 pixel |
Resolution Z (@Sdc ... Sde) | 5 µm |
Repeat accuracy Z | 2 µm |
Linearity deviation Z | ± 0.1 % MR |
Temperature drift | ± 0.04 %Sde/K |
Laser class | 2 |
Laser wavelength | Blue (405 nm) |
Max. laser power | 18 mW |
Light point shape (at reference distance) | Line Length (x) 28 mm, Line Width (z) < 50 µm |
Software / parametrisation | Integrated Webserver for parametrisation |
Interfaces / output circuit | Fast-Ethernet 100-MBit/s, 2 x Switching Output, Analog Output |
Protocols | Profinet (CC-A), Ethernet/IP, Modbus TCP, OPC UA, UDP, IO-Link |
Voltage supply range +Vs | 18 ... 30 VDC |
Analog output signal | 4-20mA, 2-10mA, 0-10V, 0-5V |
Switching outputs | 2 x Outputs (Push-Pull) |
Power supply | typ. 2.4W (100 mA max at 24 V), IEEE 802.3af Power over Ethernet (PoE) |
Electrical connection | M12, 12-pin, A-coded, male |
Ethernet connection | M12 8-pol, X-coded, female |
Trigger input specification | High Level: 8 V ... +Ub / PoE 8 ... 24 V, Low Level: < 2.5 V |
Material | Case: Aluminium, Front Cover: Glass |
Dimensions (W x H x D) | 36 mm x 74 mm x 60 mm |
Width | 36 mm |
Height | 74 mm |
Depth | 60 mm |
Weight | 270 g |
Ambient temperature | 0 ... + 45 °C |
Storage temperature | - 10 ... + 60 °C |
Ambient humidity | 20 ... 85 % |
Protection class (IEC 60529) | IP 65 |
Vibration (sinusoidal) | 1 mm p-p at f = 10 - 55 Hz, duration 5 min per axis, 30 min endurance at f = 55 Hz per axis, IEC 60068-2-6:2008 |
Shock (semi-sinusoidal) | 30 g / 11 ms, 6 jolts per axis and direction, IEC 60068-2-27:2009 |
Ambient light immunity | < 25 kLux |
Conformity | CE, UL |
Encoder input specifications | 4 Inputs Differential: A/B, HTL / TTL available, High Level: 2.5 V ... +Ub / PoE 2.5 ... 24 V, Low Level: < 1.5 V, Max. Frequency 30kHz |
Ask for the Pricing of Baumer Smart Vision Sensor Solutions OXS200-B02A.E02 part no: 11728848 at unbeatable prices. Detailed Specifications of OXS200-B02A.E02, 11728848 feature measurement range (MR) of 25 mm and a clearance distance of 60 mm. The field of view spans 20 mm ... 28 mm with a resolution X of 30 ... 40 µm and profile points of 700 pixel. The resolution Z ranges from 5 µm, with a repeat accuracy of 2 µm. The sensor uses a red laser with a wavelength of Blue (405 nm) and a maximum laser power of 18 mW. Operating on a voltage supply range of 18 ... 30 VDC, the sensor supports analog output signals such as 4-20mA, 2-10mA, 0-10V, 0-5V. It offers 2 x Outputs (Push-Pull) switching outputs and is equipped with an M12, 12-pin, A-coded, male connector and M12 8-pol, X-coded, female. The sensor is housed in a durable Case: Aluminium, Front Cover: Glass front cover, and its dimensions are 36 mm x 74 mm x 60 mm. Now's the Time to Secure a Quote for your requirement of Baumer Smart Vision Sensor Solutions. We're committed to offering more favorable pricing and more responsive support than other Traders.
