UF200.D50-UAMJ.72CU: 11708324 - Baumer Distance Measurement With Sensor
Technical Specifications Baumer Distance Measurement With Sensor UF200.D50-UAMJ.72CU 11708324:
| Spec | Value |
|---|---|
| Scanning range Sd | 15 … 500 mm |
| Scanning range close limit Sdc | 15 … 500 mm |
| Output circuit | Voltage output |
| Connection types | Cable 4 pin, 2 m |
Baumer Distance Measurement With Sensor UF200.D50-UAMJ.72CU, 11708324 Technical Specifications:
| Specification | Value |
|---|---|
| Scanning range Sd | 15 … 500 mm |
| Scanning range close limit Sdc | 15 … 500 mm |
| Scanning range far limit Sde | 15 … 500 mm |
| Version | IO-Link dual channel |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Resolution | < 0.3 mm |
| Response time ton/toff standard | < 40 ms |
| Temperature drift | < 2 % of distance to target Sde |
| Power-up drift | Compensated after 15 min. |
| Sonic frequency | 290 kHz |
| Adjustment | qTeach, line-Teach, IO-Link |
| Light indicator | LED yellow |
| Power on indication | LED green |
| Alignment measuring axis | < 2° |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption typ. | 12 mA |
| Output circuit | Voltage output |
| Baud rate | 38,4 kBaud (COM 2) |
| Output signal | 0 ... 10 V / 10 ... 0 V |
| Output current | |
| Voltage drop Vd | |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes, Vs to GND |
| Interface | IO-Link V1.1 |
| Cycle time | ≥ 8 ms |
| Process data length | 48 Bit |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Width / diameter | 20.5 mm |
| Height / length | 41 mm |
| Depth | 15 mm |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -25 … +65 °C |
| Storage temperature | -25 … +75 °C |
| Protection class | IP 67 |
Call us for Baumer Distance Measurement With Sensor UF200.D50-UAMJ.72CU part no: 11708324 at the best rates. Technical Attributes of UF200.D50-UAMJ.72CU, 11708324 are scanning range of 15 … 500 mm with a resolution of less than < 0.3 mm and operates at a sonic frequency of 290 kHz. The adjustment options include qTeach, line-Teach, IO-Link for flexible setup. It has a LED yellow light indicator for operational status and operates within a voltage supply range of 12 … 30 VDC, with a typical current consumption of 12 mA. The sensor uses a Voltage output circuit and is housed in a robust Rectangular design made of Plastic (ASA, PMMA). Its compact dimensions include a width of 20.5 mm and a height of 41 mm. The connection is facilitated through an Cable 4 pin, 2 m. Unlock Exclusive Pricing with a Quote for your requirement of Baumer Distance Measurement With Sensor. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
