UF200.DA0-IAMO.72CU: 11708342 - Baumer Ultrasonic Range Detector
Technical Specifications Baumer Ultrasonic Range Detector UF200.DA0-IAMO.72CU 11708342:
| Spec | Value |
|---|---|
| Scanning range Sd | 20 … 1000 mm |
| Scanning range close limit Sdc | 20 … 1000 mm |
| Output circuit | Current output |
| Connection types | Cable 4 pin, 2 m |
Baumer Ultrasonic Range Detector UF200.DA0-IAMO.72CU, 11708342 Technical Specifications:
| Specification | Value |
|---|---|
| Scanning range Sd | 20 … 1000 mm |
| Scanning range close limit Sdc | 20 … 1000 mm |
| Scanning range far limit Sde | 20 … 1000 mm |
| Version | IO-Link dual channel |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Resolution | < 0.3 mm |
| Response time ton/toff standard | < 60 ms |
| Temperature drift | < 2 % of distance to target Sde |
| Power-up drift | Compensated after 15 min. |
| Sonic frequency | 220 kHz |
| Adjustment | qTeach, IO-Link |
| Light indicator | LED yellow |
| Power on indication | LED green |
| Alignment measuring axis | < 2° |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption typ. | 13 mA |
| Output circuit | Current output |
| Baud rate | 38,4 kBaud (COM 2) |
| Output signal | 4 ... 20 mA / 20 ... 4 mA |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes, Vs to GND |
| Interface | IO-Link V1.1 |
| Cycle time | ≥ 12 ms |
| Process data length | 48 Bit |
| Design | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Width / diameter | 20.5 mm |
| Height / length | 41 mm |
| Depth | 15 mm |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -25 … +65 °C |
| Storage temperature | -25 … +75 °C |
| Protection class | IP 67 |
Obtain a Quote for Baumer Ultrasonic Range Detector
UF200.DA0-IAMO.72CU part no: 11708342 at economical prices. Specifications Overview for UF200.DA0-IAMO.72CU, 11708342 reveals scanning range of 20 … 1000 mm with a resolution of less than < 0.3 mm and operates at a sonic frequency of 220 kHz. The adjustment options include qTeach, IO-Link for flexible setup. It has a LED yellow light indicator for operational status and operates within a voltage supply range of 12 … 30 VDC, with a typical current consumption of 13 mA. The sensor uses a Current output circuit and is housed in a robust Rectangular design made of Plastic (ASA, PMMA). Its compact dimensions include a width of 20.5 mm and a height of 41 mm. The connection is facilitated through an Cable 4 pin, 2 m. Take the First Step with a Quote for your requirement of Baumer Ultrasonic Range Detector
