UNAM 12P1912/S14: 10156843 - Baumer Ultrasonic Sensor With PNP Output
Technical Specifications of Baumer Ultrasonic Sensor With PNP Output UNAM 12P1912/S14 10156843:
| Spec | Value |
|---|---|
| Scanning range Sd | 40 … 400 mm |
| Scanning range far limit Sde | 60 … 400 mm |
| Output circuit | PNP make function (NO) |
| Connection types | Connector M12 |
Baumer Ultrasonic Sensor With PNP Output UNAM 12P1912/S14, 10156843 Technical Specifications:
| Specification | Value |
|---|---|
| Scanning range Sd | 40 … 400 mm |
| Scanning range far limit Sde | 60 … 400 mm |
| Version | |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Temperature drift | < 0,18 % Sde/K |
| Power-up drift | |
| Response time ton/toff min | |
| Response time ton/toff standard | |
| Sonic frequency | 290 kHz |
| Adjustment | External Teach-in |
| Light indicator | |
| Power on indication | |
| Alignment measuring axis | |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption typ. | |
| Output circuit | PNP make function (NO) |
| Output current | 200 mA |
| Voltage drop Vd | <2 VDC |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | |
| Baud rate | |
| Cycle time | |
| Process data length | |
| Design | Cylindrical threaded |
| Housing material | Brass nickel plated |
| Width / diameter | 12 mm |
| Height / length | 70 mm |
| Depth | |
| Connection types | Connector M12 |
| Operating temperature | -10 … +60 °C |
| Storage temperature | |
| Protection class | IP 67 |
| Output indicator | LED green |
Mail Us for your needs in Baumer Ultrasonic Sensor With PNP Output UNAM 12P1912/S14 part no: 10156843 with budget-friendly prices. The Main Technical Parameters of UNAM 12P1912/S14, 10156843 inludce scanning range of 40 … 400 mm. This sensor has a hysteresis of 4 % Sde and operates at a sonic frequency of 290 kHz. It features External Teach-in, adjustment options, providing flexible configuration. The sensor operates within a voltage supply range of 12 … 30 VDC and uses a PNP make function (NO) output circuit, supporting an output current of up to 200 mA. Designed in compact Cylindrical threaded housing, it measures 12 mm in width and 70 mm in height, making it suitable for various industrial applications. The housing is made from durable Brass nickel plated, ensuring longevity in demanding environments. The sensor connects via an Connector M12, offering easy integration into your system. Customize Your Experience with a Quote for your requirement of Baumer Ultrasonic Sensor With PNP Output. Experience the difference with our competitive pricing and superior support over other Suppliers.
