UNCK 09T9114/D1: 11004100 - Baumer Small Object Ultrasonic Sensor
Technical Specifications of Baumer Small Object Ultrasonic Sensor UNCK 09T9114/D1 11004100:
| Spec | Value |
|---|---|
| Scanning range Sd | 3 ... 150 mm |
| Output circuit | RS232 |
| Design | Rectangular |
| Connection Types | Cable PUR 4 x 0,08, 2 m |
Baumer Small Object Ultrasonic Sensor UNCK 09T9114/D1, 11004100 Technical Specifications:
| Specification | Value |
|---|---|
| Scanning range Sd | 3 ... 150 mm |
| Version | - |
| Hysteresis typ. | - |
| Repeat accuracy | (filter active) < 0.1 mm |
| Response time ton | < 7 ms |
| Release time toff | - |
| Sonic frequency | 380 kHz |
| Adjustment | - |
| Light indicator | Yellow LED / red LED |
| Power on indication | - |
| Alignment measuring axis | - |
| Voltage supply range +Vs | 15 … 30 VDC |
| Output circuit | RS232 |
| Output current | - |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes, Vs to GND |
| Interface | - |
| Baud rate | - |
| Cycle time | - |
| Process data length | - |
| IO-Link port type | - |
| IO-Link | - |
| Design | Rectangular |
| Housing material | PA 12 |
| Width / diameter | 8.6 mm |
| Height / length | 82 mm |
| Depth | 24.5 mm |
| Connection types | Cable PUR 4 x 0,08, 2 m |
| Operating temperature | 0 … +60 °C |
| Protection class | IP 67 |
Please speak to our Technical Engineer for Baumer Small Object Ultrasonic Sensor 11004100 part no: 10 at attractive prices. Technical Specs Summary of UNCK 09T9114/D1, 11004100 includes sensor operates within a range of 3 ... 150 mm, with an accuracy of (filter active) < 0.1 mm. It features a fast response time of < 7 ms and operates at a frequency of 380 kHz. The sensor supports - for easy setup and includes Yellow LED / red LED indicators for status monitoring. It operates on a 15 … 30 VDC power supply and provides a RS232 with a current consumption of -. The sensor is housed in a Rectangular body made of PA 12, measuring 8.6 mm in diameter and 82 mm in length. It includes an Cable PUR 4 x 0,08, 2 m and is rated IP 67, ensuring protection against dust and water. The sensor operates reliably in temperatures from 0 … +60 °C. Match Your Needs with a Quote for your requirement of Baumer Small Object Ultrasonic Sensor. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
