UNDK 10N8914/S35A: 10161446 - Baumer NO/NC Ultrasonic Proximity Sensor
Technical Specifications of Baumer NO/NC Ultrasonic Proximity Sensor UNDK 10N8914/S35A 10161446:
| Spec | Value |
|---|---|
| Scanning range Sd | 10 … 200 mm |
| Scanning range far limit Sde | 30 … 200 mm |
| Output circuit | NPN make function (NO) / break function (NC) |
| Connection types | Connector M8 |
Baumer NO/NC Ultrasonic Proximity Sensor UNDK 10N8914/S35A, 10161446 Technical Specifications:
| Specification | Value |
|---|---|
| Scanning range Sd | 10 … 200 mm |
| Scanning range far limit Sde | 30 … 200 mm |
| Version | |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Temperature drift | < 0,18 % Sde/K |
| Power-up drift | |
| Response time ton/toff min | |
| Response time ton/toff standard | |
| Sonic frequency | 380 kHz |
| Adjustment | Teach-in |
| Light indicator | |
| Power on indication | |
| Alignment measuring axis | |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption typ. | |
| Output circuit | NPN make function (NO) / break function (NC) |
| Output current | 200 mA |
| Voltage drop Vd | <2 VDC |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | |
| Baud rate | |
| Cycle time | |
| Process data length | |
| Design | Rectangular |
| Housing material | Plastic (ASA) |
| Width / diameter | 10.4 mm |
| Height / length | 27 mm |
| Depth | 14 mm |
| Connection types | Connector M8 |
| Operating temperature | -10 … +60 °C |
| Storage temperature | |
| Protection class | IP 67 |
| Output indicator | LED green |
Give Us a Call for Baumer NO/NC Ultrasonic Proximity Sensor UNDK 10N8914/S35A part no: 10161446 at the lowest pricing. In-depth Technical Analysis of UNDK 10N8914/S35A, 10161446 feature scanning range of 10 … 200 mm. This sensor has a hysteresis of 4 % Sde and operates at a sonic frequency of 380 kHz. It features Teach-in, adjustment options, providing flexible configuration. The sensor operates within a voltage supply range of 12 … 30 VDC and uses a NPN make function (NO) / break function (NC) output circuit, supporting an output current of up to 200 mA. Designed in compact Rectangular housing, it measures 10.4 mm in width and 27 mm in height, making it suitable for various industrial applications. The housing is made from durable Plastic (ASA), ensuring longevity in demanding environments. The sensor connects via an Connector M8, offering easy integration into your system. Elevate Your Project with a Quote for your requirement of Baumer NO/NC Ultrasonic Proximity Sensor . Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
