UNDK 20P7803/S35A: 10166946 - Baumer 1000 mm Range Ultrasonic Sensor
Technical Specifications of Baumer 1000 mm Range Ultrasonic Sensor UNDK 20P7803/S35A 10166946:
| Spec | Value |
|---|---|
| Scanning range Sd | 100 … 1000 mm |
| Scanning range far limit Sde | 100 … 1000 mm |
| Output circuit | PNP break function (NC) |
| Connection types | Connector M8 |
Baumer 1000 mm Range Ultrasonic Sensor UNDK 20P7803/S35A, 10166946 Technical Specifications:
| Specification | Value |
|---|---|
| Scanning range Sd | 100 … 1000 mm |
| Scanning range far limit Sde | 100 … 1000 mm |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Temperature drift | < 0,18 % Sde/K |
| Sonic frequency | 240 kHz |
| Adjustment | Teach-in |
| Voltage supply range +Vs | 12 … 30 VDC |
| Output circuit | PNP break function (NC) |
| Output current | 200 mA |
| Voltage drop Vd | <2 VDC |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Housing material | Polyester |
| Width / diameter | 20 mm |
| Height / length | 42 mm |
| Depth | 15 mm |
| Connection types | Connector M8 |
| Operating temperature | -10 … +60 °C |
| Protection class | IP 67 |
| Output indicator | LED green |
Obtain a Quote for Baumer 1000 mm Range Ultrasonic Sensor UNDK 20P7803/S35A part no: 10166946 at economical prices. Specifications Overview for UNDK 20P7803/S35A, 10166946 reveals scanning range of 100 … 1000 mm. This sensor has a hysteresis of 4 % Sde and operates at a sonic frequency of 240 kHz. It features Teach-in, adjustment options, providing flexible configuration. The sensor operates within a voltage supply range of 12 … 30 VDC and uses a PNP break function (NC) output circuit, supporting an output current of up to 200 mA. Designed in compact Rectangular housing, it measures 20 mm in width and 42 mm in height, making it suitable for various industrial applications. The housing is made from durable Polyester, ensuring longevity in demanding environments. The sensor connects via an Connector M8, offering easy integration into your system. Take the First Step with a Quote for your requirement of Baumer 1000 mm Range Ultrasonic Sensor. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
