UNDK 20U6914/S35A: 10146711 - Baumer Ultrasonic Sensor Distance Range
Technical Specifications of Baumer Ultrasonic Sensor Distance Range UNDK 20U6914/S35A 10146711:
| Spec | Value |
|---|---|
| Scanning range Sd | 20 … 200 mm |
| Output circuit | Voltage output |
| Design | Rectangular |
| Connection Types | Connector M8 |
Baumer Ultrasonic Sensor Distance Range UNDK 20U6914/S35A, 10146711 Technical Specifications:
| Specification | Value |
|---|---|
| Scanning range Sd | 20 … 200 mm |
| Version | - |
| Hysteresis typ. | - |
| Repeat accuracy | 0.5 mm |
| Response time ton | < 30 ms |
| Release time toff | < 30 ms |
| Sonic frequency | 380 kHz |
| Adjustment | Teach-in |
| Light indicator | Yellow LED / red LED |
| Power on indication | - |
| Alignment measuring axis | - |
| Voltage supply range +Vs | 15 … 30 VDC |
| Output circuit | Voltage output |
| Output current | 20 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | - |
| Baud rate | - |
| Cycle time | - |
| Process data length | - |
| IO-Link port type | - |
| IO-Link | - |
| Design | Rectangular |
| Housing material | Polyester |
| Width / diameter | 20 mm |
| Height / length | 42 mm |
| Depth | 15 mm |
| Connection types | Connector M8 |
| Operating temperature | -10 … +60 °C |
| Protection class | IP 67 |
IndMALL Offers Baumer Ultrasonic Sensor Distance Range UNDK 20U6914/S35A part no: 10146711 at economical Choices. Product Tech Specs of UNDK 20U6914/S35A, 10146711 include sensor operates within a range of 20 … 200 mm, with an accuracy of 0.5 mm. It features a fast response time of < 30 ms and operates at a frequency of 380 kHz. The sensor supports Teach-in for easy setup and includes Yellow LED / red LED indicators for status monitoring. It operates on a 15 … 30 VDC power supply and provides a Voltage output with a current consumption of 20 mA. The sensor is housed in a Rectangular body made of Polyester, measuring 20 mm in diameter and 42 mm in length. It includes an Connector M8 and is rated IP 67, ensuring protection against dust and water. The sensor operates reliably in temperatures from -10 … +60 °C. Now's the Time to Secure a Quote for your requirement of Baumer Ultrasonic Sensor Distance Range. Trust in our superior pricing and more dedicated support over other Distributors.
