UNDK 30N1713: 10123577 - Baumer 250 mm Range Ultrasonic Proximity Sensor
Technical Specifications of Baumer 250 mm Range Ultrasonic Proximity Sensor UNDK 30N1713 10123577:
| Spec | Value |
|---|---|
| Scanning range Sd | 30 … 250 mm |
| Scanning range far limit Sde | 30 … 250 mm |
| Output circuit | NPN make function (NO) |
| Connection types | Cable, L=2 m |
Baumer 250 mm Range Ultrasonic Proximity Sensor UNDK 30N1713, 10123577 Technical Specifications:
| Specification | Value |
|---|---|
| Scanning range Sd | 30 … 250 mm |
| Scanning range far limit Sde | 30 … 250 mm |
| Version | |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Temperature drift | < 0,18 % Sde/K |
| Power-up drift | |
| Response time ton/toff min | |
| Response time ton/toff standard | |
| Sonic frequency | 300 kHz |
| Adjustment | Potentiometer |
| Light indicator | |
| Power on indication | |
| Alignment measuring axis | |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption typ. | |
| Output circuit | NPN make function (NO) |
| Output current | 200 mA |
| Voltage drop Vd | <2 VDC |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | |
| Baud rate | |
| Cycle time | |
| Process data length | |
| Design | Rectangular |
| Housing material | Polyester / die-cast zinc |
| Width / diameter | 30 mm |
| Height / length | 65 mm |
| Depth | 31 mm |
| Connection types | Cable, L=2 m |
| Operating temperature | -25 … +60 °C |
| Storage temperature | |
| Protection class | IP 67 |
| Output indicator | LED green |
Call us for Baumer 250 mm Range Ultrasonic Proximity Sensor UNDK 30N1713 part no: 10123577 at the best rates. Technical Attributes of UNDK 30N1713, 10123577 are scanning range of 30 … 250 mm. This sensor has a hysteresis of 4 % Sde and operates at a sonic frequency of 300 kHz. It features Potentiometer, adjustment options, providing flexible configuration. The sensor operates within a voltage supply range of 12 … 30 VDC and uses a NPN make function (NO) output circuit, supporting an output current of up to 200 mA. Designed in compact Rectangular housing, it measures 30 mm in width and 65 mm in height, making it suitable for various industrial applications. The housing is made from durable Polyester / die-cast zinc, ensuring longevity in demanding environments. The sensor connects via an Cable, L=2 m, offering easy integration into your system. Unlock Exclusive Pricing with a Quote for your requirement of Baumer 250 mm Range Ultrasonic Proximity Sensor. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
