UNDK 30N3703: 10233439 - Baumer Ultrasonic Proximity Sensor NPN
Technical Specifications of Baumer Ultrasonic Proximity Sensor NPN UNDK 30N3703 10233439:
| Spec | Value |
|---|---|
| Scanning range Sd | 100 … 1000 mm |
| Scanning range far limit Sde | 100 … 1000 mm |
| Output circuit | NPN break function (NC) |
| Connection types | Cable, L=2 m |
Baumer Ultrasonic Proximity Sensor NPN UNDK 30N3703, 10233439 Technical Specifications:
| Specification | Value |
|---|---|
| Scanning range Sd | 100 … 1000 mm |
| Scanning range far limit Sde | 100 … 1000 mm |
| Version | |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | 0.5 mm |
| Temperature drift | < 0,1 % Sde/K |
| Power-up drift | |
| Response time ton/toff min | |
| Response time ton/toff standard | |
| Sonic frequency | 240 kHz |
| Adjustment | Potentiometer |
| Light indicator | |
| Power on indication | |
| Alignment measuring axis | |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption typ. | |
| Output circuit | NPN break function (NC) |
| Output current | 200 mA |
| Voltage drop Vd | <2 VDC |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Interface | |
| Baud rate | |
| Cycle time | |
| Process data length | |
| Design | Rectangular |
| Housing material | Polyester / die-cast zinc |
| Width / diameter | 30 mm |
| Height / length | 65 mm |
| Depth | 31 mm |
| Connection types | Cable, L=2 m |
| Operating temperature | -10 … +60 °C |
| Storage temperature | |
| Protection class | IP 67 |
| Output indicator | LED green |
Obtain a Quote for Baumer Ultrasonic Proximity Sensor NPN UNDK 30N3703 part no: 10233439 at economical prices. Specifications Overview for UNDK 30N3703, 10233439 reveals scanning range of 100 … 1000 mm. This sensor has a hysteresis of 4 % Sde and operates at a sonic frequency of 240 kHz. It features Potentiometer, adjustment options, providing flexible configuration. The sensor operates within a voltage supply range of 12 … 30 VDC and uses a NPN break function (NC) output circuit, supporting an output current of up to 200 mA. Designed in compact Rectangular housing, it measures 30 mm in width and 65 mm in height, making it suitable for various industrial applications. The housing is made from durable Polyester / die-cast zinc, ensuring longevity in demanding environments. The sensor connects via an Cable, L=2 m, offering easy integration into your system. Take the First Step with a Quote for your requirement of Baumer Ultrasonic Proximity Sensor NPN. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
