UR12.P50-GP2C.7BCU: 11704845 - Baumer Ultrasonic 2 Point Proximity Sensor
Technical Specifications of Baumer Ultrasonic 2 Point Proximity Sensor UR12.P50-GP2C.7BCU 11704845:
| Spec | Value |
|---|---|
| Scanning range Sd | 15 … 500 mm |
| Scanning range far limit Sde | 15 … 500 mm |
| Output circuit | Push-pull |
| Connection types | Cable 5 pin, 2 m |
Baumer Ultrasonic 2 Point Proximity Sensor UR12.P50-GP2C.7BCU, 11704845 Technical Specifications:
| Specification | Value |
|---|---|
| Scanning range Sd | 15 … 500 mm |
| Scanning range far limit Sde | 15 … 500 mm |
| Version | IO-Link dual channel, Multiplex version |
| Hysteresis typ. | 4 % Sde |
| Repeat accuracy | < 0.5 mm |
| Temperature drift | > 50 mm < 2 % of distance to target Sde, < 50 mm ± 1 mm |
| Power-up drift | Compensated after 15 min. |
| Response time ton/toff min | < 16 ms |
| Response time ton/toff standard | < 40 ms |
| Sonic frequency | 290 kHz |
| Adjustment | line-Teach, IO-Link |
| Light indicator | LED yellow |
| Power on indication | LED green |
| Alignment measuring axis | < 2° |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption typ. | 35 mA |
| Output circuit | Push-pull |
| Output current | 100 mA |
| Voltage drop Vd | <3 VDC |
| Residual ripple | < 10 % Vs |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes, Vs to GND |
| Interface | IO-Link V1.1 |
| Baud rate | 38,4 kBaud (COM 2) |
| Cycle time | ≥ 8 ms |
| Process data length | 48 Bit |
| Design | Cylindrical threaded |
| Housing material | Brass nickel plated |
| Width / diameter | 12 mm |
| Height / length | 50 mm |
| Depth | |
| Connection types | Cable 5 pin, 2 m |
| Operating temperature | -25 … +65 °C |
| Storage temperature | -40 … +75 °C |
| Protection class | IP 67 |
| Output indicator | Yellow LED / red LED |
Talk to Our Engineer for Baumer Ultrasonic 2 Point Proximity Sensor UR12.P50-GP2C.7BCU part no: 11704845 with exclusive offers. Core System Specifications of UR12.P50-GP2C.7BCU, 11704845 are scanning range of 15 … 500 mm. This IO-Link dual channel, Multiplex version sensor has a hysteresis of 4 % Sde and operates at a sonic frequency of 290 kHz. It features line-Teach, IO-Link, adjustment options, providing flexible configuration. The sensor operates within a voltage supply range of 12 … 30 VDC and uses a Push-pull output circuit, supporting an output current of up to 100 mA. Designed in compact Cylindrical threaded housing, it measures 12 mm in width and 50 mm in height, making it suitable for various industrial applications. The housing is made from durable Brass nickel plated, ensuring longevity in demanding environments. The sensor connects via an Cable 5 pin, 2 m, offering easy integration into your system. Don't Miss Out on a Quote for your requirement of Baumer Ultrasonic 2 Point Proximity Sensor. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
