DOP-B03E211: Delta 0ºC ~ 50ºC Operating Temperature HMI
Technical Specifications of Delta 0ºC ~ 50ºC Operating Temperature HMI DOP-B03E211:
| Spec | Value |
|---|---|
| Display | 4.3" TFT LCD |
| Color | 65536 colors |
| Resolution Pixels | 480 x 272 |
| Back Light | LED Back Light |
Delta 0ºC ~ 50ºC Operating Temperature HMI DOP-B03E211 Technical Specifications:
| Specification | Value |
|---|---|
| Display | 4.3" TFT LCD |
| Color | 65536 colors |
| Resolution Pixels | 480 x 272 |
| Back Light | LED Back Light |
| Luminance (cd/m2 ) | 400 |
| Back Light Life (Hour)*1 | 20,000 |
| MCU | 401 MHz |
| Flash ROM (Bytes) | 128 MB |
| RAM (Bytes) | 64MB |
| Backup Memory (Bytes) | 16MB |
| Buzzer | Multi-Tone Frequency（2K ~ 4K Hz）／ 85dB |
| Ethernet | 1 Port (Note 2) |
| USB | 1 USB Host Ver 1.1 / 1 USB Client Ver 2.0 |
| Memory Card | N/A |
| Serial COM1/2/3 Port | COM1 RS-232 (Supports hardware flow control) / RS-485 COM2 RS-422 / RS-S485 COM3 N/A |
| Perpetual Calendar (RTC) | Built-in |
| Cooling Method | Natural air circulation |
| Safety Approval | CE ／ UL |
| Waterproof Degree | IP65 ／ UL type 4x |
| Operation Voltage*3 | DC +24V（-10% ~ +15%） |
| Voltage Endurance | AC500V for 1 minute (between charging DC24 terminal and FG terminals) |
| Power Consumption*5 | 2.64 W |
| Backup Battery | 3V lithium battery CR2032 x 1 |
| Backup Battery Life | It depends on the temperature used and the conditions of usage, about 3 years or more at 25 o C |
| Operation Temperature | 0 oC ~ 50 o C |
| Storage Temperature | -20 o C ~ +60 o C |
| Ambient Humidity | 10% ~ 90% RH (0 ~ 40° C), 10% ~ 55% RH (41 ~ 50 o C), Pollution Degree 2 |
| Viberation | IEC 61131-2 compliant 5Hz ~ 8.3Hz = Continuous: 3.5mm, 8.3Hz ~ 150Hz = Continuous: 1.0g |
| Shock | IEC 60068-2-27 compliant 15g peak for 11 ms duration, X, Y, Z directions for 6 times |
| Dimensions (W) x (H) x (D) mm | 129 x103 × 39 |
| Mounting Dimensions (W) x (H) mm | 118.8 × 92.8 |
| Weight | Approx. 264 g |
Obtain a Quote for Delta 0ºC ~ 50ºC Operating Temperature HMI, DOP-B03E211 at attractive prices. Core System Specifications of DOP-B03E211 are 480 x 272, LED Back Light, 400, 20000 401 MHz 128 MB. It functionality Includes 4.3" TFT LCD, 65536 colors, 64MB 16MB Multi-Tone Frequency（2K ~ 4K Hz）／ 85dB. Elevate Your Project with a Quote for your requirement of Delta 0ºC ~ 50ºC Operating Temperature HMI. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
