DVP04DA-S: Delta PLC 4 Points Analog Output
Technical Specifications of DVP04DA-S Delta PLC 4 Points Analog Output
| Spec | Value |
|---|---|
| Built-in | RS-485 interface |
| Power Supply Voltage | 24VDC (-15%~20%) |
| Resolution | 12-bit |
| Voltage input/output | Output voltage (0 V ~ +10 V) |
| Current input/output | Output current (0 mA ~ +20 mA) |
Delta PLC 4 Points Analog Output DVP04DA-S Technical Specifications:
| Specification | Value |
|---|---|
| Built-in | RS-485 interface |
| Power Supply Voltage | 24VDC (-15%~20%) |
| Resolution | 12-bit |
| Analog I/O Modules | 4 points of analog |
| Fuse capacity | ES: 2A/ 250VAC; SV: 2.5A/ 30VDC |
| Power Consumption | 4W |
| Voltage input/output | Output voltage (0 V ~ +10 V) |
| Current input/output | Output current (0 mA ~ +20 mA) |
| Spike Voltage Durability | 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) |
| Insulation Impedance | >5 MΩ (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storagr Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Storage Operation Humidity | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Response Time | 3ms |
| Input Signal Voltage | 24VDC ±10% (5 mA) |
IndMALL Automation Offers Delta PLC 4 Points Analog Output DVP04DA-S at the lowest pricing. In-depth Technical Analysis of DVP04DA-S includes 4 points of analog output voltage (0V~+10V)/ current (0 mA~+20 mA), Output resolution: 12-bit, Built-in RS-485 interface. And It Delivers ES: 2A/ 250VAC; SV: 2.5A/ 30VDC fuse, 24VDC (-15%~20%) supply, >5 MΩ (all I/O point-to-ground: 500VDC). Capture the Best Deal with a Quote for your requirement of Delta PLC 4 Points Analog Output. Our promise: More affordable pricing and more personalized support than other Dealers.
