DVP04PT-S: Delta PLC PT100 Module
Technical Specifications of DVP04PT-S Delta PLC PT100 Module
| Spec | Value |
|---|---|
| Built-in | RS-485 interface |
| Power Supply Voltage | 24VDC (-15%~20%) |
| Resolution | 0.1 °C |
| Voltage input/output | - |
| Current input/output | - |
Delta PLC PT100 Module DVP04PT-S Technical Specifications:
| Specification | Value |
|---|---|
| Built-in | RS-485 interface |
| Power Supply Voltage | 24VDC (-15%~20%) |
| Resolution | 0.1 °C |
| Analog I/O Modules | 4 points of platinum RTD (Pt100, Pt1000, Ni100, Ni1000) sensor input*1 (Version 4.06 and above supports Pt1000, Ni100, Ni1000) |
| Fuse capacity | ES: 2A/ 250VAC; SV: 2.5A/ 30VDC |
| Power Consumption | 2W |
| Voltage input/output | - |
| Current input/output | - |
| Spike Voltage Durability | 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) |
| Insulation Impedance | >5 MΩ (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storagr Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Storage Operation Humidity | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Response Time | 3ms |
| Input Signal Voltage | 24VDC ±10% (5 mA) |
Give Us a Call for Delta PLC PT100 Module DVP04PT-S at the lowest pricing. In-depth Technical Analysis of DVP04PT-S includes 4 points of platinum RTD (Pt100, Pt1000, Ni100, Ni1000) sensor input*1 (Version 4.06 and above supports Pt1000, Ni100, Ni1000), Resolution 0.1 °C, Built-in RS-485 interface. It functionality Includes ES: 2A/ 250VAC; and SV: 2.5A/ 30VDC fuse, 24VDC (-15%~20%) power supply. Elevate Your Project with a Quote for Your Requirement for the Delta PLC PT100 Module. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
