VFD004E21T : Delta VFD 2.5 Amp
Technical Specifications of Delta VFD 2.5 Amp VFD004E21T:
- Series: E
- Input Voltage: 230V Single-phase
- Motor Output (kW): 0.4 kW
- Motor Output (HP): 0.5 HP
- Output Capacity (kVA): 1 kVA
- Cooling Method: Natural Cooling
- Enclosure Rating: IP20.
Delta VFD 2.5 Amp VFD004E21T Technical Specifications:
| Series Name | E |
| Input Voltage / Frequency | 230V, Single, 200-240V, 50/60Hz |
| Applicable Motor Output ( kW) | 0.4 kW |
| Applicable Motor Output (HP) | 0.5 HP |
| Output Current (A) | 2.5 A |
| Output Capacity (kVA) | 1 kVA |
| Cooling Method | Natural Cooling |
| IP Level | IP20 |
| Pollution Degree | 2 |
| Storage/Transportation Temperature | 20’C~60’C |
| Ambient Humidity | Below 90% RH (non-condensing) |
| Version Type | T: Frame A, built-in brake chopper |
| V/F Pattem | SPWM (Sinusoidal Pulse Width Modulation) Control (V/F or sensorless vector control) |
| Input Frequency Tolerance | ±5% (47-63Hz) |
| Voltage Tolerance | ±10% (180-264V) |
| Net Weight | 1.1 kg |
IndMALL offers the Delta VFD004E21T, a Series E Delta VFD with a 2.5 Amp rating, featuring an input voltage of 230V single-phase, a motor output of 0.4 kW (0.5 HP), an output capacity of 1 kVA, natural cooling, and an enclosure rating of IP20.
