VFD11AME21ANSAA: Delta 3HP VFD
Technical Specifications of VFD11AME21ANSAA Delta 3HP VFD:
| Spec | Value |
|---|---|
| Series Name | ME300 |
| Input Voltage Frequency | 230V, Single-phase AC, 200V~240V (-15% ~ + 10%), 50 / 60Hz |
| Applicable Motor Output ( kW) | 2.2 |
| Applicable Motor Output (HP) | 3 |
| Output Frequency | 0.00 ~ 599.00 Hz (±0.1%) |
Delta 3HP VFD11AME21ANSAA Technical specifications:
| Specification | Value |
|---|---|
| Series Name | ME300 |
| Input Voltage / Frequency | 230V, Single-phase AC, 200V~240V (-15% ~ + 10%), 50 / 60Hz |
| Applicable Motor Output ( kW) | 2.2 |
| Applicable Motor Output (HP) | 3 |
| Heavy Duty Rated Output Current (A) | 11 |
| Normal Duty Rated Output Current (A) | 12.5 |
| Cooling Method | Fan cooling |
| IP Level | IP20 |
| EMC Filter | None |
| Safe Torque Off (STO) | STO Model |
| Model Type | Standard model |
| Braking Chopper | Built-in |
| Output Frequency | 0.00 ~ 599.00 Hz (±0.1%) |
| MODBUS COM | Built-in |
| Control Methods | V/F, SVC |
| Size: W × H (mm) | 87 x 157 |
| Size: D (mm) | 136 |
| Net Weight | 1.5 |
IndMALL Offers the Delta VFD11AME21ANSAA, a powerful Delta 3HP VFD from the ME300 series. This VFD operates on a 230V, single-phase AC input voltage and delivers a motor output of 2.2 kW (3 HP) with an output current of 11 A. It features built-in braking chopper and fan cooling, making it an ideal choice for various industrial applications. The Delta VFD11AME21ANSAA also provides reliable protection with its IP20 rating and offers versatile control methods, including V/F and SVC, making it a standard model for efficient motor control.
