VFD11AMS21ANSHA: Delta 230V Single-phase 2.2kW Drive
Technical Specifications of VFD11AMS21ANSHA Delta 230V Single-phase 2.2kW Drive:
| Spec | Value |
|---|---|
| Series Name | MS300 |
| Input Voltage Frequency | 230V, Single-phase AC 200 V ~240 V (-15% ~ +10%), 50 / 60 Hz |
| Applicable Motor Output ( kW) | 2.2 kW |
| Applicable Motor Output (HP) | 3 HP |
| Output Frequency | 0.00 ~ 1500.0Hz (±0.1%) |
Delta 230V Single-phase 2.2kW Drive VFD11AMS21ANSHA Technical Specifications:
| Specification | Value |
|---|---|
| Series Name | MS300 |
| Input Voltage / Frequency | 230V, Single-phase AC 200 V ~240 V (-15% ~ +10%), 50 / 60 Hz |
| Applicable Motor Output ( kW) | 2.2 kW |
| Applicable Motor Output (HP) | 3 HP |
| Heavy Duty Rated Output Current (A) | 11 A |
| Normal Duty Rated Output Current (A) | 12.5 A |
| Cooling Method | Fan cooling |
| IP Level | IP20 |
| EMC Filter | None EMC Filter |
| Safe Torque Off (STO) | Integrated STO |
| Model Type | High Speed Model |
| Braking Chopper | Built-in Braking Chopper |
| Output Frequency | 0.00 ~ 1500.0Hz (±0.1%) |
| MODBUS COM | - |
| Control Methods | V/F, SVC, FOC Sensorless |
| Size: W × H (mm) | 87×157 |
| Size: D (mm) | 152 |
| Net Weight | 3.5 kg |
Get A Quote for Delta 230V Single-phase 2.2kW Drive, VFD11AMS21ANSHA at the best price. Here are the brief Technical Specifications of VFD11AMS21ANSHA are High Speed Model, Integrated STO, None EMC Filter & IP20. And it offers 2.2 kW 3 HP & 11 A. It's Time to get a Quote for your requirement of Delta 230V Single-phase 2.2kW Drive. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
