VFD11AMS21ENSHA: Delta Built-in EMC Filter 2.2kW VFD
Technical Specifications of VFD11AMS21ENSHA Delta Built-in EMC Filter 2.2kW VFD:
| Spec | Value |
|---|---|
| Series Name | MS300 |
| Input Voltage Frequency | 230V, Single-phase AC 200 V ~240 V (-15% ~ +10%), 50 / 60 Hz |
| Applicable Motor Output ( kW) | 2.2 kW |
| Applicable Motor Output (HP) | 3 HP |
| Output Frequency | 0.00 ~ 1500.0Hz (±0.1%) |
Delta Built-in EMC Filter 2.2kW VFD11AMS21ENSHA Technical Specifications:
| Specification | Value |
|---|---|
| Series Name | MS300 |
| Input Voltage / Frequency | 230V, Single-phase AC 200 V ~240 V (-15% ~ +10%), 50 / 60 Hz |
| Applicable Motor Output ( kW) | 2.2 kW |
| Applicable Motor Output (HP) | 3 HP |
| Heavy Duty Rated Output Current (A) | 11 A |
| Normal Duty Rated Output Current (A) | 12.5 A |
| Cooling Method | Fan cooling |
| IP Level | IP40 (Anti-dust) |
| EMC Filter | None EMC Filter |
| Safe Torque Off (STO) | Integrated STO |
| Model Type | High Speed Model |
| Braking Chopper | Built-in Braking Chopper |
| Output Frequency | 0.00 ~ 1500.0Hz (±0.1%) |
| MODBUS COM | - |
| Control Methods | V/F, SVC, FOC Sensorless |
| Size: W × H (mm) | 87×157 |
| Size: D (mm) | 152 |
| Net Weight | 3.5 kg |
Obtain a Quote for Delta Built-in EMC Filter 2.2kW VFD, VFD11AMS21ENSHA at economical prices. Specifications Overview for VFD11AMS21ENSHA reveals High Speed Model, Integrated STO, None EMC Filter & Built-in Braking Chopper. It also includes 2.2 kW, 3 HP & 11 A. Take the First Step with a Quote for your requirement of Delta Built-in EMC Filter 2.2kW VFD. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
