VFD1320C43A: Delta VFD 175 HP
Technical Specifications of Delta VFD 175 HP VFD1320C43A:
| Spec | Value |
|---|---|
| Input Voltage / Frequency | 3 - phase AC 380V ~ 480V (-15%~+10% ), 50/60Hz |
| Output Capacity (kVA) Normal Duty | 207 kVA |
| Output Current (A) Normal Duty | 260 A |
| Applicable Motor Output (kW) Normal Duty | 132 kW |
| Applicable Motor Output (HP) Normal Duty | 175 HP |
Delta VFD 175 HP VFD1320C43A Technical Specifications:
| Specification | Value |
|---|---|
| Input Voltage / Frequency | 3 - phase AC 380V ~ 480V (-15%~+10% ), 50/60Hz |
| Output Capacity (kVA) Normal Duty | 207 kVA |
| Output Current (A) Normal Duty | 260 A |
| Applicable Motor Output (kW) Normal Duty | 132 kW |
| Applicable Motor Output (HP) Normal Duty | 175 HP |
| Cooling Method | Fan Cooling |
| Efficiency (%) | 98.2 |
| IP Level | IP20 |
| NEMA Protection Level | No NEMA Protection Level |
| Storage/Transportation Temperature | -25 ~ 70 |
| Braking Chopper | Optional Braking Chopper |
| Control Method | Pulse Width Modulated (PWM) |
| Installation Type | Wall mount |
| V/F Curve | 4-point adjustable V/F curve and square curve |
| Input Frequency Tolerance | 47 ~ 63Hz |
| Voltage Tolerance | 323 ~ 528 VAC |
| Drive Weight (Kg) | 86.5±1.5 kg |
Call us for Delta VFD 175 HP, VFD1320C43A at the best rates. Technical Attributes of VFD1320C43A are Optional Braking Chopper, Pulse Width Modulated (PWM), Wall mount & No NEMA Protection Level. And It Delivers 207 kVA, 260 A & 132 kW.Unlock Exclusive Pricing with a Quote for your requirement of Delta VFD 175 HP. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
