VFD25AMS23ANSAA : Delta VFD 230V three Phase
Technical Specifications of Delta VFD 230V three Phase VFD25AMS23ANSAA:
- Series: MS300
- Input Voltage: 230V Three-phase
- Motor Output (kW): 5.5KW
- Motor Output (HP): 7.5 HP
- Cooling Method: Fan cooling
- Control Methods: V/F, SVC, FOC Sensorless.
Delta VFD 230V three Phase VFD25AMS23ANSAA Technical Specifications:
| Series Name | MS300 |
| Input Voltage / Frequency | 3-phase AC 200 V ~240 V，50 / 60 Hz |
| Applicable Motor Output ( kW) | 5.5 kW |
| Applicable Motor Output (HP) | 7.5 HP |
| Heavy Duty Rated Output Current | 25 A |
| Normal Duty Rated Output Current | 27 A |
| Cooling Method | Fan cooling |
| IP Level | IP20 |
| EMC Filter | None |
| Safe Torque Off (STO) | Integrated STO |
| Model Type | Standard model |
| Verson | A |
| Input Mains Frequency Range (Hz) | 47 ~ 63 |
| Control Methods | V/F, SVC, FOC Sensorless |
| Size: W × H (mm) | 109×207 |
| Size: D (mm) | 154 |
| Net Weight | 4.25 kg |
IndMALL offers the Delta VFD25AMS23ANSAA, a high-performance Delta VFD 230V three-phase model from the MS300 series, featuring a 5.5KW motor output (7.5 HP), fan cooling, and advanced control methods including V/F, SVC, and FOC Sensorless.
