VFD25AMS23ENSHA: Delta 230V 3-phase 25 Amp
Technical Specifications of VFD25AMS23ENSHA Delta 230V 3-phase 25 Amp:
| Spec | Value |
|---|---|
| Series Name | MS300 |
| Input Voltage Frequency | 230V, Three-phase AC 200 V ~240 V，50 / 60 Hz |
| Applicable Motor Output ( kW) | 5.5 kW |
| Applicable Motor Output (HP) | 7.5 HP |
| Output Frequency | 0.00 ~ 1500.0Hz (±0.1%) |
Delta 230V 3-phase 25 Amp VFD25AMS23ENSHA Technical Specifications:
| Specification | Value |
|---|---|
| Series Name | MS300 |
| Input Voltage / Frequency | 230V, Three-phase AC 200 V ~240 V，50 / 60 Hz |
| Applicable Motor Output ( kW) | 5.5 kW |
| Applicable Motor Output (HP) | 7.5 HP |
| Heavy Duty Rated Output Current (A) | 25 A |
| Normal Duty Rated Output Current (A) | 27 A |
| Cooling Method | Fan cooling |
| IP Level | IP40 (Anti-dust) |
| EMC Filter | None EMC Filter |
| Safe Torque Off (STO) | Integrated STO |
| Model Type | High Speed Model |
| Braking Chopper | Built-in Braking Chopper |
| Output Frequency | 0.00 ~ 1500.0Hz (±0.1%) |
| MODBUS COM | - |
| Control Methods | V/F, SVC, FOC Sensorless |
| Size: W × H (mm) | 109×207 |
| Size: D (mm) | 154 |
| Net Weight | 4.25 kg |
Call us for Delta 230V 3-phase 25 Amp, VFD25AMS23ENSHA at the best rates. Technical Attributes of VFD25AMS23ENSHA are High Speed Model, Integrated STO, None EMC Filter & Built-in Braking Chopper. And It Delivers 5.5 kW, 7.5 HP & 25 A.Unlock Exclusive Pricing with a Quote for your requirement of Delta 230V 3-phase 25 Amp. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
