VFD4A2ME43AFNAA: Delta 4.2A VFD
Technical Specifications of VFD4A2ME43AFNAA Delta 4.2A VFD:
| Spec | Value |
|---|---|
| Series Name | ME300 |
| Input Voltage Frequency | 460V, Three-phase AC, 380V~480V (-15% ~ + 10%), 50 / 60Hz |
| Applicable Motor Output ( kW) | 1.5 |
| Applicable Motor Output (HP) | 2 |
| Output Frequency | 0.00 ~ 599.00 Hz (±0.1%) |
Delta 4.2A VFD4A2ME43AFNAA Technical specifications:
| Specification | Value |
|---|---|
| Series Name | ME300 |
| Input Voltage / Frequency | 460V, Three-phase AC, 380V~480V (-15% ~ + 10%), 50 / 60Hz |
| Applicable Motor Output ( kW) | 1.5 |
| Applicable Motor Output (HP) | 2 |
| Heavy Duty Rated Output Current (A) | 4.2 |
| Normal Duty Rated Output Current (A) | 4.6 |
| Cooling Method | Fan cooling |
| IP Level | IP20 |
| EMC Filter | Built-In |
| Safe Torque Off (STO) | None |
| Model Type | Standard model |
| Braking Chopper | Built-in |
| Output Frequency | 0.00 ~ 599.00 Hz (±0.1%) |
| MODBUS COM | Built-in |
| Control Methods | V/F, SVC |
| Size: W × H (mm) | 72 × 142 |
| Size: D (mm) | 143 |
| Net Weight | 0.8 |
IndMALL offers the Delta VFD4A2ME43AFNAA, a powerful VFD (Variable Frequency Drive) with the Series ME300. This VFD operates on a 460V, three-phase AC input voltage and delivers a motor output of 1.5 kW (2 HP) with an output current of 4.2 A. The built-in EMC filter and braking chopper, along with fan cooling, ensure efficient and reliable performance. This standard model VFD supports control methods like V/F and SVC, providing robust protection with an IP20 rating, making it an excellent choice for various industrial applications.
