VFD4A8ME21AFNAA: Delta Built-in EMC Filter 1HP Drive
Technical Specifications of VFD4A8ME21AFNAA Delta Built-in EMC Filter 1HP Drive:
| Spec | Value |
|---|---|
| Series Name | ME300 |
| Input Voltage Frequency | 230V, Single-phase AC, 200V~240V (-15% ~ + 10%), 50 / 60Hz |
| Applicable Motor Output ( kW) | 0.75 |
| Applicable Motor Output (HP) | 1 |
| Output Frequency | 0.00 ~ 599.00 Hz (±0.1%) |
Delta Built-in EMC Filter 1HP Drive VFD4A8ME21AFNAA Technical specifications:
| Specification | Value |
|---|---|
| Series Name | ME300 |
| Input Voltage / Frequency | 230V, Single-phase AC, 200V~240V (-15% ~ + 10%), 50 / 60Hz |
| Applicable Motor Output ( kW) | 0.75 |
| Applicable Motor Output (HP) | 1 |
| Heavy Duty Rated Output Current (A) | 4.8 |
| Normal Duty Rated Output Current (A) | 5 |
| Cooling Method | Fan cooling |
| IP Level | IP20 |
| EMC Filter | Built-In |
| Safe Torque Off (STO) | None |
| Model Type | Standard model |
| Braking Chopper | Built-in |
| Output Frequency | 0.00 ~ 599.00 Hz (±0.1%) |
| MODBUS COM | Built-in |
| Control Methods | V/F, SVC |
| Size: W × H (mm) | 87 x 157 |
| Size: D (mm) | 163 |
| Net Weight | 1 |
The Delta Built-in EMC Filter 1HP Drive, part of the ME300 series, is a high-performance solution designed for industrial applications, featuring a 230V, single-phase AC input and delivering a motor output of 0.75 kW (1 HP) with an output current of 4.8 A. This standard model, identified as VFD4A8ME21AFNAA, comes with fan cooling, a built-in EMC filter, and a braking chopper, ensuring efficient operation and compliance with IP20 protection standards. IndMALL offers this advanced control unit, which supports both V/F and SVC control methods, making it a versatile choice for a wide range of applications.
